36
Fan Size 36”
Wheel Dia. 36.5 inches 927 mm
Inlet Area 9.52 square feet 0.884 m 2
Outlet Area 8.30 square feet 0.771 m 2
Tip Speed 9.56 x RPM 2.914
ft./minute m/minute
Minimum Fan RPM (Without VFRB Option)
Motor Minimum Fan RPM
1800 RPM 400
1200 RPM 266
Performance
Data Q Fan and
Super Q II
Size 36
Table P-8 — Size 36 Q-Fan
CFM Out- Total Static Pressure
Std. let 1 /
4
” 3 /
8
” 1 /
2
” 5 /
8
” 3 /
4
” 1” 1 1 /
4
” 1 1 /
2
” 1 3 /
4
” 2”
Air Vel. RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
6000 722 409 0.4 446 0.5 481 0.6 515 0.8 550 1.0
6800 819 445 0.5 4.78 0.6 510 0.8 541 0.9 571 1.1 633 1.5
7600 915 483 0.5 512 0.7 542 0.9 570 1.1 598 1.2 651 1.6 708 2.1
8400 1012 523 07 549 08 575 1.0 602 1.2 628 1.4 677 1.8 725 2.2 776 2.8
9200 1108 564 08 586 10 611 1.2 635 1.4 659 1.6 706 2.0 750 2.5 795 3.0 841 3.5
10000 1204 605 1.0 626 1.2 647 1.4 670 1.6 692 1.8 736 2.3 779 2.7 819 3.2 860 3.7 902 4.3
10800 1301 648 1.2 666 1.4 686 1.6 706 1.8 727 2.0 769 2.5 809 3.0 847 3.5 885 4.1 922 4.6
11600 1397 690 1.4 708 1.6 725 1.8 744 2.0 763 2.3 802 2.8 840 3.3 877 3.8 912 4.4 948 5.0
12400 1493 733 1.6 749 1.8 766 2.1 783 2.3 800 2.6 836 3.1 873 3.7 908 4.2 943 4.8 975 5.4
13200 1590 777 1.9 792 2.1 807 2.4 823 2.6 839 2.9 872 3.4 906 4.0 940 4.6 973 5.2 1006 5.8
14000 1686 820 2.2 834 2.4 849 2.7 863 2.9 878 3.2 909 3.8 941 4.4 973 5.0 1005 5.7 1036 6.3
14800 1783 864 2.6 877 2.8 891 3.1 904 3.3 918 3.6 947 4.2 977 4.8 1007 5.5 1038 6.1 1068 6.8
15600 1879 908 2.9 920 3.2 933 3.5 946 3.7 959 4.0 986 4.6 1014 5.3 1042 5.9 1071 6.6 1100 7.3
16400 1975 952 3.4 964 3.6 976 3.9 988 4.2 1000 4.5 1026 5.1 1052 5.7 1079 6.4 1106 7.2 1134 7.9
17200 2072 996 3.8 1008 4.1 1019 4.4 1030 4.7 1042 5.0 1066 5.6 1090 6.3 1116 7.0 1142 7.7 1168 8.5
18000 2168 1041 4.3 1051 4.6 1062 4.9 1073 5.2 1084 5.5 1107 6.2 1130 6.8 1154 7.6 1178 8.4 1203 9.1
18800 2265 1085 4.9 1095 5.2 1106 5.5 1116 5.8 1127 6.1 1148 6.8 1170 7.5 1192 8.2 1215 9.0 1239 9.8
19600 2361 1130 5.5 1139 5.8 1149 6.1 1159 6.4 1169 6.7 1190 7.4 1211 8.1 1232 8.9 1254 9.7 1276 10.5
20400 2457 1174 6.1 1183 6.4 1193 6.8 1202 7.1 1212 7.4 1232 8.1 1251 8.9 1272 9.6 1293 10.4 1314 11.3
21200 2554 1219 6.8 1228 7.1 1237 7.5 1246 7.8 1255 8.2 1274 8.9 1293 9.6 1312 10.4 1332 11.2 1352 12.1
22000 2650 1263 7.6 1272 7.9 1281 8.3 1290 8.6 1298 9.0 1316 9.7 1335 10.5 1353 11.3 1372 12.1 1391 13.0
22800 2746 1308 8.4 1316 8.7 1325 9.1 1333 9.4 1342 9.8 1359 10.6 1377 11.4 1394 12.2 1412 13.0 1431 13.9
23600 2843 1353 9.2 1361 9.6 1369 10.0 1377 10.3 1385 10.7 1402 11.5 1419 12.3 1436 13.1 1453 14.0 1471 14.9
24400 2939 1398 10.2 1405 10.5 1413 10.9 1421 11.3 1429 11.7 1445 12.5 1461 13.3 1478 14.2 1494 15.0 1511 15.9
CFM Out- Total Static Pressure
Std. let 2 1 / 4 ” 2 1 / 2 ” 3” 3 1 / 2 ” 4” 4 1 / 2 ” 5” 5 1 / 2 ” 6” 6 1 / 2 ”
Air Vel. RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
12000 1445 996 5.8 1029 6.4 1100 7.9
12800 1542 1022 6.2 1054 6.9 1118 8.2 1185 9.8
13600 1638 1052 6.7 1081 7.3 1142 8.7 1202 10.2 1266 12.0
14400 1734 1082 7.2 1111 7.9 1167 9.3 1223 10.8 1282 12.4 1342 14.2
15200 1831 1113 7.8 1141 8.4 1195 9.9 1249 11.4 1302 13.0 1358 14.8 1415 16.7
16000 1927 1145 8.4 1172 9.1 1225 10.5 1276 12.1 1327 13.7 1378 15.4 1431 17.3 1485 19.3
16800 2024 1178 9.0 1204 9.7 1256 11.2 1306 12.8 1354 14.4 1403 16.2 1451 18.0 1501 19.9 1553 22.1 1606 24.4
17600 2120 1211 9.6 1237 10.4 1287 12.0 1335 13.6 1382 15.2 1428 17.0 1475 18.8 1521 20.7 1569 22.8 1618 25.0
18400 2216 1245 10.3 1270 11.1 1319 12.8 1366 14.4 1412 16.1 14S6 17.9 1501 19.7 1544 21.6 1589 23.6 1635 25.8
19200 2313 1281 11.0 1304 11.9 1351 13.6 1398 15.3 1442 17.0 1486 18.9 1528 20.7 1571 22.6 1612 24.6 1655 26.7
20000 2409 1317 11.8 1340 12.6 1385 14.4 1430 16.3 1473 18.0 1516 19.9 1558 21.8 1598 23.7 1639 25.7 1679 27.7
20800 2506 1354 12.6 1376 13.5 1419 15.3 1462 17.2 1505 19.1 1546 20.9 1587 22.9 1628 24.9 1666 26.9 1705 29.0
21600 2602 1392 13.4 1412 14.4 1454 16.2 1496 18.2 1537 20.2 1578 22.1 1618 24.0 1657 26.1 1694 28.1 1732 30.2
22400 2698 1430 14.3 1449 15.3 1489 17.2 1529 19.2 1570 21.2 1610 23.3 1648 25.2 1687 27.3 1725 29.4 1760 31.5
23200 2795 1469 15.3 1488 16.2 1526 18.3 1564 20.3 1604 22.4 1642 24.5 1680 26.6 1717 28.6 1754 30.8 1791 33.0
24000 2891 1508 16.3 1526 17.3 1563 19.3 1600 21.4 1637 23.6 1675 25.7 1713 27.9 1749 30.1 1785 32.2 1821 34.4
24800 2987 1548 17.4 1565 18.4 1600 20.4 1636 22.6 1672 24.8 1709 27.0 1745 29.3 1781 31.5 1816 33.8 1851 35.9
25600 3084 1589 18.6 1605 19.6 1638 21.6 1673 23.8 1708 26.1 1743 28.4 1779 30.7 1814 33.0 1848 35.3 1882 37.5
26400 3180 1629 19.8 1645 20.8 1677 22.9 1710 25.1 1744 27.4 1778 29.8 1812 32.1 1847 34.5 1880 36.9 1914 39.3
27200 3277 1670 21.1 1686 22.1 1716 24.2 1748 26.5 1781 28.8 1814 31.2 1847 33.6 1880 36.1 1913 38.5 1946 41.0
28000 3373 1712 22.5 1726 23.5 1756 25.7 1787 27.9 1818 30.3 1850 32.7 1882 35.2 1914 37.7 1947 40.2 1979 42.8
28800 3469 1753 23.9 1767 25.0 1796 27.1 1826 29.4 1856 31.8 1887 34.3 1918 36.8 1949 39.4 198O 42.0 2012 44.5
29600 3566 1795 25.4 1809 26.5 1836 28.7 1865 31.0 1894 33.4 1924 35.9 1954 38.5 1984 41.1 2014 43.8 2045 46.4
30400 3662 1837 27.0 1850 28.1 1877 30.3 1905 32.7 1933 35.1 1961 37.6 1991 40.3 2020 42.9 2049 45.6 2079 48.3
CFM Out- Total Static Pressure
Std. let 7” 7 1 / 2 ” 8” 8 1 / 2 ” 9” 9 1 / 2 ” 10” 10 1 / 2 ” 11” 11 1 / 2 ”
Air Vel. RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
19000 2289 16.95 28.7 1740 31.1 1787 33.6
19800 2385 1714 29.6 1757 32.0 1800 34.4 1845 37.0 1891 39.7
20600 2481 1737 30.8 1777 33.0 1818 35.4 1860 37.9 1902 40.6 1946 43.3
21400 2578 1764 32.1 1801 34.2 1839 36.6 1878 39.0 1918 41.6 1958 44.3 2000 47.1 2042 50.1
22200 2674 1790 33.4 1827 35.7 1863 37.9 1900 40.3 1937 42.8 1976 45.4 2014 48.2 2054 51.1 2094 54.0
23000 2771 1818 34.8 1854 37.1 1889 39.4 1925 41.8 1959 44.2 1996 46.8 2032 49.4 2070 52.2 2107 55.2 2145 58.2
23800 2867 1848 36.3 1881 38.6 1916 40.9 1950 43.4 1985 45.8 2018 48.2 2053 50.9 2088 53.6 2124 56.5 2160 59.4
24600 2963 1878 37.9 1912 40.2 1944 42.5 1977 45.0 2011 47.5 2044 50.0 2076 52.5 2109 55.2 2143 58.0 2178 60.8
25400 3060 1908 39.5 1941 41.9 1974 44.3 2005 46.7 2037 49.2 2070 51.8 2102 54.4 2133 56.9 2165 59.6 2198 62.5
26200 3156 1939 41.1 1971 43.6 2004 46.0 2036 48.5 2065 51.0 2097 53.6 2128 56.2 2160 58.9 2191 61.7
27000 3253 1970 43.1 2002 45.3 2034 47.8 2065 50.4 2096 53.0 2125 55.5 2155 58.1 2186 60.9 2216 63.6
27800 3349 2002 44.9 2034 47.4 2064 49.7 2095 52.3 2126 55.0 2156 57.6 2184 60.2 2213 62.9
28600 3445 2035 46.7 2065 49.3 2096 51.9 2126 54.3 2156 57.0 2185 59.7 2215 62.4
29400 3542 2067 48.6 2098 51.3 2128 54.0 2157 56.4 2186 59.1 2215 61.9
30200 3638 2101 50.6 2130 53.3 2160 56.1 2189 58.8
31000 3734 2134 52.6 2164 55.4 2192 58.2
Performance based on 0.075 lbs. per cubic foot density (air at 70 F and 29.92 Hg Bar). Performance shown is for installation Type B: free inlet, ducted outlet.
Power rating (BHP) does not include drive losses. Performance ratings do not include the effects of appurtenances in the airstream.
When inlet vanes are used increase rpm 1 percent and brake horsepower 3 percent.
Fan tables cover part of fan operating range; fan curves show full operating range.
Pressure Class Limits
Class Maximum RPM
I 1228
II 1647
III 2217
