Thermaltake EPS 12V - Manual (Page 7)

-Tough Atomic Energy
Build for the Extreme-
-Tough Atomic Energy
Build for the Extreme-
ATX 12V 2.2 & EPS 12V Version ATX 12V 2.2 Version & EPS 12V
11 10
T
echnology Features
T
otal Output Connector
C
able Application
F
eatures:
4.2 Touhgpower 750W PSU Specification
-Complies with ATX 12V 2.2 & EPS 12V version.
-SLI, CrossFire , and Dual Core CPU ready.
-Next generation four +12V rails(12V1, 12V2, 12V3, 12V4) supports
high-end graphic card and PC system (combined loading of 60A).
-Independent Voltage Circuit: offers unflappable current delivery under
heavy load and makes voltage output more stable.
-Active Power Factor Correction (PF>0.99) and high efficiency (up to 85%).
-Extremely good voltage regulation (¡Ó 3%): provides steady voltage for
system.
-Industrial grade components
(capacitor, transformer, etc)
-High reliability:
MTBF>120,000 hours.
-Mirror effect housing and
reliable 14cm ball-bearing
fan.
-Protections: Over Current,
Over Voltage, and
Short-Circuit protection.
-Safety / EMI Approvals: CE,
CB, TUV, FCC, UL, CUL, and
BSMI certified.
up to 85%
16 ms
90VAC - 264VAC
Active PFC
750 Watts
SPECIFICATION
16cm(L)x15cm(W)x8.5cm(H)
100VAC / 10A max.
200VAC / 5A max.
INPUT
DIMENSIONS
W0117
16 dBA at 1300 RPM
2.6 kg
ATX Logic on-off additional power
rocker switch
Black
14cm Fan
SPEED: 1900 RPM(+10%~-10%)
DIMENSION: 140 X 140 X 25 mm
AIR FLOW: 82 CFM
TEMP. AUTO CONTROL
100-500 ms
+5V 7.0 Vmax
+3.3V 4.5 Vmax
+12V 15.6 Vmax
47 - 63 Hz
P/N
Maximum Power
Color
Switches
PFC
(Power Factor
Correction)
Cooling System
Noise
P. G. Signal
Over Voltage
Protection
Recycle AC
to Reset
Unit Size
Net Weight
Input Voltage
Input
Frequency
Range
Input Current
Hold-up Time
Efficiency
Toughpower 750W Toughpower 750W
O U T P U T
Load
Reg.
+3%
- 3%
Min.
Load
0.5A
Max.
Load
30A
Voltage +3.3V +5V +12V
1
+5VSB +12V
2
+12V
3
+12V
4
12V
28A 18A 18A 18A 18A 0.8A 3.0A
2.0A 1.0A 1.0A 1.0A 1.0A 0A 0A
+3%
- 3%
+3%
- 3 %
+5%
- 3%
+3%
- 3 %
+3%
- 3 %
+3%
- 3 %
+9%
- 5%
Ripple
& Noise
50
mV
50
mV
120
mV
120
mV
120
mV
120
mV
120
mV
50
mV
Reak
Load 3.5A - - - - - - -
All cables with black cable sleeving
Optimum air-flow in the chassis
Quad +12V Rails and EPS Structure Mirror Effect
Housing
Six S-ATA
Connectors
Silent 140mm Fan
X1 X1 X1
24-pin
Main Connector
8-pin +12V
Power Connector
4-pin +12V
Power Connector
X8 X2 X6 X2
4-pin Peripheral
Power Connector
4-pin Floppy Drive
Connector
5-pin S-ATA
Connector
6-pin PC Express
Connector
Intelligent Cable Management:
Noise Preventive Silicon Pad - Effectively
reduces vibration noise by as much as 80%
170 X 140 mm
