Page 11
7
Models BC10/BW11
Operator Parts Identification
BC10 Exploded View Parts Identification
ITEM
DESCRIPTION
PART NO.
1
CAP-MIXER
051484
2
SCREW-MIXER-RETAINER CAP
051487
3
BRAKE (SEAL) MIXER
051485
4
MOTOR-MIXER (120V)
051481-12
4
MOTOR-MIXER (220/240V)
051481-27
4a
PLATE-MOTOR MOUNTING TOP
051481-4
4b
BEARING-MIXER MOTOR
051481-2
4c
PLATE-MOTOR MTG. BOTTOM
051481-1
5
CAPACITOR-MIXER (220/240V)
051483
5
CAPACITOR-MIXER (120V)
051482
6
FRAME-MIXER-STAINLESS STL
051480
7
BREAKER-CIRCUIT-MIXER-
3A-120V
051490
7
BREAKER-CIRCUIT-MIXER-
5A-220/ 240V
051489
8
SCREW-MIXER-MTG PIVOT PIN
051508
9
CORD-MIXER-18/3 GROUNDED
051491
10
PEDAL-FOOT-MIXER-115V
052451
10*
PEDAL-FOOT-MIXER-220V
053192
10a
TRANSMITTER FOOT PEDAL
052451-1
10b
CONTROLLER-FOOT PEDAL-
115V
052451-2
ITEM
DESCRIPTION
PART NO.
10b* SWITCH-PRESS.-FOOT PEDAL-
220V
053192-1
10c
TUBE-AIR-FOOT PEDAL
052451-3
11
GUARD-SWITCH-MIXER
051505
12
SWITCH-ROCKER-MIXER
051488
13
SCREW-MIXER-MOTOR MTG
051493
14
PIN PIVOT-MIXER
051507
15
SLINGER-MIXER
051494
16
SHAFT-MIXER-AGITATOR-EXT
051495
17
AGITATOR-MIXER-PERM SOFT
051497
18
FOOT A.-MIXER-PLUGGED
051500
19
GUARD-SPLASH-MIXER
051499
20
LABEL-MIXER-COUNTER-
RAZZLE
052250
*
CAP-CRIMP-MIXER
051504
*
JUMPER WIRES-MIXER
051486
*
MANUAL-OPERATOR-MIXER
052544-M
*
RELIEF-STRAIN-MIXER-R ANGLE
051492
*
TAB INSULATOR-MIXER
(CAPACITOR)
051509
*
TIES-CABLE-MIXER
(CAPACITOR)
051502
* NOT SHOWN
