www.tanaka-usa.com
PARTS INFORMATION
TPH-270PF/PN
ENGINE / CYLINDER, PISTON, CRANKCASE, IGNITION • FIGURE 1
ITEM
PART NUMBER
DESCRIPTION
QTY
COMMENTS
1-1
1570168090
CAP,SPARK PLUG ASS’Y
1
1-2
0181161021
PLUG,SPARK
1
1-3
2550168020
COVER,SPARK PLUG,RUBBER 1
1-6
0010168090
SET,CYLINDER
1
Includes cylinder gasket
1-7
99461050184
BOLT,HEX,5X18,S
4
1-9
0170168020
GASKET,CYLINDER
1
1-11
04101601200
RING,PISTON
2
1-12
0300168090
SET,PISTON
1
Includes rings & circlips
1-13
03900000201
CIRCLIP,PISTON PIN
2
1-14
03701700200
PIN,PISTON
1
1-16
0460168080
CRANKSHAFT
1
1-17
99962091325
BEARING,NEEDLE,F-910
1
1-18
06810100200
KEY,WOODRUFF,3X13X4.5
1
1-19
33000200210
SHIM,12.2X19X.10
V
Shims are "as needed" to obtain
1-19
33000200220
SHIM,12.2X19X.15
V
correct side clearance
1-19
33000200230
SHIM,12.2X19X.20
V
1-19
33000200240
SHIM,12.2X19X.30
V
1-21
99101080011
NUT,8
1
1-22
79801630200
PULLEY,STARTER
1
1-26
35910112203
WASHER,CLUTCH B
1
1-31
0720168090
CRANKCASE,ASSY
1
Crankcase assy includes bearings, seals
1-32
99966122240
SEAL,OIL,#12227
1
and gasket.
1-33
99961600100
BEARING,BALL,#6001
2
1-34
0900168020
GASKET,CRANKCASE
1
1-36
99414050251
SCREW,5X25
2
1-37
99011050381
SCREW,5X38
2
1-38
99210050012
WASHER,S,5
2
1-40
1910168090
WIRE,LEAD ASS’Y
1
1-46
99416040186
SCREW,WS,4X18
2
1-47
1820186A201
WASHER,SPECIAL
2
1-50
1672174390
COIL,IGNITION ASS’Y
1
1-51
1552174380
ROTOR,MAGNETO
1
1-52
99200080011
WASHER,8
1
1-54
99101080011
NUT,8
1
1-55
2500168020
TUBE,INSULATOR
1
