PARTS INFORMATION
TPH-270PF/PN
CUTTING BLADES, TOOLS • FIGURE 8
ITEM
PART NUMBER
DESCRIPTION
QTY
COMMENTS
0-1
81320000200
WRENCH,HEX,4
1
0-2
03629331501
SPANNER,COMBI
1
ITEM PART NUMBER
DESCRIPTION
QTY
COMMENTS
8-1
1003228021
SHAFT,CAM
1
8-2
1013316022
ROD,CAM
2
8-3
0753228020
PLATE,GUIDE
2
8-4
1223316021
GUIDE,CUTTER 625MM
1
~A290200
8-4
1223228621
GUIDE,CUTTER 1
A290201~
8-5
CB-21A
BLADE,CUTTER,THT-210/2100
2
~U288058
8-5
1203228721
CUTTER,A
2
U288059~
8-6
1243320221
BOLT,CUTTER FIXING,A
4
~A290200
8-6
1243228720
BOLT,FIXING,A
4
A290201~
8-7
12933202201
WASHER,7
4
8-8
1233317A20
NUT,CUTTER FIXING
4 ~A290200
8-8 40927 NUT,FLANGE,M6 4 A290201~
8-9
99052060165
BOLT,HEX,6X16
2
8-10
08533160200
SEAL,GREASE A
1
8-11
1053228020
HOLDING,PLATE
1
8-12
3283328021
COVER,GEAR CASE "B"
1
8-13
99961608004
BEARING,BALL,608DD
1
8-14
99461040104
BOLT,HEX,4X10,S
2
8-15
99461040124
BOLT,HEX 4X12
6
8-16
13833160200
COVER,CUTTER,22"
1
8-61
1253228720
BOLT,CUTTER FIXING,B
3
A290201~
