24 and 16 Port Smart Switch II – User Manual Page 3
Features: -
! 24 or 16 x Auto-sensing 10/100Base-T RJ-45 Ethernet
ports
! 1 x Option slot for 100Mb/s and dual 1000 Mb/s uplink
module.
! Meets IEEE 802.3, .3u and .3x Ethernet standards
! Uses store-and-forward switching to separate collision
domains and abnormal packet filtering
! Local management using an RS232 console port
! Management enables detailed control of each port
! Auto-MDI/MDI-X support on every RJ-45 port
! Support for 26 port-based VLANs (18 for 16 port switch)
! 3 Modes of Quality of service with 2 queue levels per
port
! Integral 8K MAC address table automatic learning
! Backplane bandwidth 8.8 or 7.2Gbit/s (full wire speed)
! Supports back-pressure & flow control
! Numerous diagnostic LED indicators
! Internal AC/DC power unit
! Stand-alone or mountable in 19” racking
! FCC Class A, CE mark certification
Technical Support and Service
If you require technical advice for these products, please see the
FAQ pages on the web address
http://www.lan-electronics.com
If you still have problems, please contact us using the support form
located on the above web site.
If you have a faulty unit then please contact us through the web site
to arrange for a replacement unit. The faulty unit must be returned to
us as part of the replacement agreement.
Product Number 0-1591093-x 0-1591047-x Issue 1
© Tyco Electronics 2005
