TECHNICAL SPECIFICATIONS
TS2.10 TS2.12
Output Power 300w rms 500w rms
Low Frequency Response (-6dB) 24Hz 21Hz
(Typical In Room)
Inputs 2 x Phono Line Level, LFE or stereo
Outputs 2 x Phono Line Level, LFE or stereo
Input Filter 50- 150Hz, 2nd Order Low Pass, with BYPASS Provision
Driver Type 250mm (10”) Active & Passive ABR 300mm (12”) Active & Passive ABR
Enclosure Type Closed Box, Side Firing
Enclosure Volume 23.1 litre (0.82 cu. ft.) 37.5 litre (1.32 cu. ft.)
Additional Features Variable Phase Control, 0 - 180 degrees
signal sense or always on operation
Enclosure Dimensions, (W x H x D) 390 x 380 x 328mm 440 x 430 x 378mm
(15.36 x 14.96 x 12.91”) (17.33 x 16.93 x 14.88”)
Enclosure Weight 14.5 kg (32 lbs) 18.2 kg (40.1 lbs)
Packed Weight 16.5 kg (36.4 lbs) 20.7 kg (45.6 lbs)
Mains Voltage 100-120V/ 220-240V 100-240V 50/60Hz
switchable 50/60Hz
NOTE: Tannoy adopts a policy of continuous improvement and product specification is subject to change
without notice.
