ENGLISH

3

Cleaning
Instructions

If the Air Purifier is in constant
use, the Electronic Filter requires
washing about once a month to
remove the particles collected
from the air. If the unit snaps fre-
quently during operation, this is
an indication that the Electronic
Filter needs to be cleaned.

Unplug unit from power

source before servicing.

Removing the
Electronic Filter

Remove the Filter Access Cover
by lifting upward. Lift the
Electronic Filter out of the cabi-
net using the handle on the top
of the filter.

Removal of
Charcoal Filter

Lift the Charcoal Filter out of the
filter rails located on the rear side
of the Filter Assembly.

Washing the Charcoal Filter with
soap and water will destroy its
ability to absorb odor. However,
lint and dirt buildup can be
removed with a vacuum cleaner
using a brush attachment.

Odor absorpton effectiveness will
gradually deteriorate and the
Charcoal Filter should be replaced
every three to four months.

Do not wash the Charcoal Filter

Filter Access Cover

Filter
Assembly

Handle

Figure 4

Figure 3

Electronic
Filter

Charcoal

Filter
