DIMENSIONAL DATA
4
MODEL
CORNER WEIGHT(LBS)
UNIT
WEIGHT
A
B
C
D
E
F
G
H
J
K
L
M
N
P
W1
W2
W3
W4
WCY024G
79
74
74
104
331
56-1/2
36
29-3/16 18-9/16 11-1/16 6-9/16 6-13/16
17
21
25-3/8
17-1/2
10
3
4-7/16
WCY030G
82
64
86
110
342
21
24-3/8
WCY036G
110
82
88
118
398
64
36
29-1/16 18-9/16 11-1/16 6-9/16
11-1/8
17
19-1/4 27-1/2
17-1/2
10
3
8-3/4
WCY042G
110
82
88
118
398
19-1/4 27-1/2
WCY048G
149
104
117
134
504
65-1/8
45
33-1/8 21-1/16 15-1/16 4-15/16
9-1/8
21-15/16
24-1/4 28-1/2
20
14
3-1/2
8-5/16
WCY060G
126
98
121
157
502
20
28
WCY024-060G OUTLINE - BACK
