2. Hardware Installation
English
2
Note:
1. After hardware installation is complete, use the Web Browser to configure
the TPE-224WS. To access the Web Browser configuration, open your web
browser, and enter the default IP Address http://192.168.0.1 and default
password "admin". Make sure your computer and the TPE-224WS are
configured to the same network segment.
2. The Mini-GBIC slots are shared with port 25 and 26 Gigabit Ethernet ports.
When the Mini-GBIC slots are in use, port 25 and 26 Gigabit Ethernet ports
are disabled.
3. Mini-GBIC slots and Gigabit Ports (ports 25, 26, 27 and 28) are not Power
over Ethernet ports.
1. Connect the Power Cord to the
rear of the TPE-224WS and then
to a power outlet.
2. Connect a CAT-5 RJ-45 network
cable from the computer to an
available Ethernet port of the
TPE-224WS.
