Specifications
• This model complies with the specifications below.
• Design and specifications are subject to change without notice.
• This model may not be compatible with features and/or specifications that may be added in the future.
Picture Tube 32 in. (802 mm) diagonal (Screen size is approximate.)
Television system NTSC standard
Channel coverage VHF: 2–13
UHF: 14–69
Cable TV: 4A, A-5–A-1, A-I,
J–W, W+1–W+84
Power source 120V AC, 60 Hz
Power consumption 137 W
Audio power 5 W + 5 W
Speaker type 2 in. x 4-11/16 in. (50.8 mm x 119.4 mm) x 2 pcs.
Video/Audio terminals S-VIDEO INPUT
Y-INPUT: 1V (p-p), 75 ohm, negative sync.
C-INPUT: 0.286V (p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT
VIDEO: 1V (p-p), 75 ohm, negative sync.
AUDIO: 150 mV (rms) (30% modulation equivalent, 47k ohm)
ColorStream ® (component video) INPUT
Y : 1V (p-p), 75 ohm
PR : 0.7V (p-p), 75 ohm
PB : 0.7V (p-p), 75 ohm
VIDEO/AUDIO OUTPUT
VIDEO: 1V (p-p), 75 ohm, negative sync.
AUDIO: 150 mV (rms) (30% modulation equivalent, 47k ohm)
Dimensions Width : 30-1/2 in. (774 mm)
Height : 27-1/16 in. (687 mm)
Depth : 22-1/2 in. (572 mm)
Weight 136.7 Ibs. (62 kg)
Supplied accessories Remote control with two size “AAA” batteries
