6
The distance from the top of the cooktop to the bottom of cabinets above must be
A = 30" (762 mm) min. This distance can be reduced to A = 24" (610 mm) when the
bottom of the wood or metal cabinet is protected by not less than 1/4" (6.35mm)
flame retardant millboard, covered by no. 28 MSG sheet steel, 0.015" (0.4 mm)
thick stainless steel, 0.024" (0.6 mm) aluminum or 0.020" (0.5 mm) thick copper.
You can find the identification plate with the electrical specifications on the
underside of the appliance. The junctionbox must be located within 3 feet of the
cooktop connection. It should be easily accessible for service purposes.
12" Approximate
J" Box
(Conduit approx. 3 feet)
Power Supply
Models CIT151DS
20 Amp circuit breaker
240 Volt, 3 Wire, 60 Hz
208 Volt, 3 Wire, 60 Hz
All with 1m flexible conduit (included)
Cabinet requirements
Electrical requiements
