T80, T85
1 403 4129 User interface, (incl.2, 3) T80 1
- 403 4130 User interface, (incl. 2, 3) T85 1
- KB 30x8 WN1411 Pt- screw 20
2 173 4078 Lower cover 1
- KB 30x12 WN1411 Pt- screw 18
- M8 DIN 934 Nut 4
3 403 4138 Safety switch 1
4 403 4055 Safety key 1
5 203 4050 Handlebar, R (incl.10 - 12) T80 1
- 203 4054 Handlebar, R (incl.10-12) T85 1
6 203 4051 Handlebar, L (incl. 11, 12) T80 1
- 203 4055 Handlebar, L (incl. 11,12) T85 1
- M8x14 ISO 7380 Head allen key screw 4
7 503 4053 Handlebar bracket 2
8 693 4005 Taper sleeve 1
- M8x90 DIN 912 Head allen key screw 1
9 533 4092 Plug, T80 1
- 533 4091 Plug, T85 1
10 213 4020 Handle grip 1
11 213 4021 Handle grip 2
12 533 4084 Handlebar end cap 2
13 503 4058 Fastening bar 4
*- M8x10 ISO 7380 Head allen key screw (*4 pcs) 8
14 403 4135 Cable, set (incl. 14a, 14b) 1
15 203 4046 Main rail, R T80 1
- 203 4052 Main rail, R T85 1
16 203 4045 Main rail, L T80 1
- 203 4053 Main rail, L T85 1
17 173 4088 Main rail end cap, R 1
- 173 4089 Main rail end cap, L 1
- M5x20 DIN 7500 C Screw 4
19 523 4029 Sleeve 4
20 533 1029 Moving wheel 4
21 503 4057 Wheel bracket, R, T80 1
- 503 4056 Wheel bracket, L, T80 1
21 503 4067 Wheel bracket, R, T85 1
- 503 4066 Wheel bracket, L, T85 1
- M8x12 ISO 7380 Head allen key screw 12
- M8 DIN 934 Nut 12
*- M10 DIN 125A Washer 4
*- M10x25 ISO 7380 Head allen key bolt 4
*- M8 DIN 125A Washer 2
*- M8x16 DIN 912 Head allen key screw 2
22 673 500 88 Snap lock 2
26 533 507 82 Stand foot 4
27 653 236 83 Washer 4
- M6x12 DIN 7991 Countersunk head screw 4
33 103 4051 Incline structure fram, T80 1
- 103 4061 Incline structure frame, T85 1
34 523 4051 Plain bearing 4
35 523 4056 Bearing housing 2
- M8x20 DIN 912 Head allen key screw 4
36 503 4060 Bracket, T80 2
- 503 4070 Bracket, T85 2
37 673 4004 Retainer ring, 20 mm 2
38 653 1015 Plastic washer 2
39 653 2002 Plastic washer 2
40 503 4061 Bracket, R, T80 1
- 503 4062 Bracket, L, T80 1
40 503 4068 Bracket, R, T85 1
- 503 4069 Bracket, L, T85 1
- M8x14 ISO 7380 Head allen key screw 4
- M10x45 ISO 7380 Head allen key bolt 2
- M8x60 ISO 7380 Head allen key screw 2
- M8 DIN 125A Washer 2
- M8 DIN 985 Locking nut 2
42 103 4053 Rear roller cover, T80 1
- 103 4062 Rear roller cover, T85 1
- M8x16 DIN 912 Head allen key screw 2
44 813 4029 Lift motor 1
- DIA 10 DIN 471 Retainer ring, 10 mm 2
45 653 4057 Screw 2
O W N E R ’ S M A N U A L
•
T 8 0 / T 8 5
117
46 693 4003 Guide 2
- M8x14 ISO 7380 Head allen key screw 4
47 433 4036 Front roller cover, T80 1
- 433 4043 Front roller cover, T85 1
- M6x8 DIN 7985 Screw 4
48 503 4059 Fastener 1
49 403 4131 Power board, 230V 1
- 403 4132 Power board, 110V 1
- M5 DIN 6798 I Star washer 1
- M4x8 DIN 7500 C Screw 2
- M5x16 DIN 7500 M Screw 4
50 103 4052 Motor bracket 1
51 652 133 74 Washer 8
- M8x16 DIN 933 Hex screw 4
- M8 DIN 934 Nut 2
- M8 DIN 125A Washer 1
- M8x35 DIN 933 Hex screw 2
52 813 4030 Motor, 2.5HP, (incl.53,54,56)T80 1
- 813 4031 Motor, 3.0HP, (incl. 53,54,56)T85 1
- M8 DIN 985 Locking nut 4
53 303 4005 Motor fan 1
54 263 4005 Drive pulley 1
- M6x8 DIN 916 Locking screw 2
55 443 4021 Drive belt 1
56 303 4010 Flywheel 1
- M6x8 DIN 916 Locking screw 2
57 403 4133 Sensor cable 1
- M4x8 DIN 7500 C Screw 2
58 523 4048 Front roller 1
- M8 DIN 125A Washer 2
- M8x25 DIN 912 Head allen key screw 2
59 693 4004 Front roller guide 1
- M6x16 DIN 912 Head allen key screw 4
60 523 4049 Rear roller 1
- M8x80 DIN 912 Head allen key screw 2
61 433 4039 Running deck 1
- M8x25 DIN 7991 Countersunk head screw 8
62 533 4079 Rubber bumper 4
- M8x10 ISO 7380 Head allen key screw 4
63 643 4008 Leaf spring 4
- M8x14 ISO 7380 Head allen key screw 4
64 433 4035 Z-plate front 1
- 4,8x16 DIN 7981 Screw 5
65 433 4034 Z-plate rear 1
- 4,8x16 DIN 7981 Screw 5
66 443 4020 Running belt 1
67 433 4040 Side landing, R 1
- 433 4041 Side landing, L 1
68 433 4024 Anti-slip mat, pair 1
69 173 4092 Right rear end cover (incl. 70) 1
71 173 4090 Left rear end cover (incl. 72) 1
- KA3,5x12WN 1411 PH PT-Screw 8
- M4x12 DIN 7500 C Screw 2
73 533 4080 Frame end plug, R 1
- 533 4081 Frame end plug, L 1
- 4,2x13 DIN 7504-N Screw 2
74 173 4087 Motor cover 1
- M5x16 DIN 7985 Screw 4
75 343 4008 Axle 1
76 403 4134 EU Power cable 1
- 403 4134 USA Power cable 1
- 403 4134 GB Power cable 1
- 403 4134 ISR Power cable 1
- 403 4134 SUI Power cable 1
77 423 4096 Lable set, T80 1
- 423 4098 Lable set, T85 1
* 553 4025 Assembly kit (incl *) 1
* 556 031 00 Allen key wrench, 5mm 1
* 556 0001 Allen key wrench, 6mm 1
- 553 0017 Screw set 1
- 403 0044 T-Ware cable 1
- 453 202 Transmitter belt 1
- 583 4030 Owner´s manual 1
