Technical specifications (DIN 45 500)
TUNER
Pre-amplifier section
Input sensitivity/impedance
EXT/MD IN
300 mV/15 k
Ω
Output level/impedance
EXT/MD OUT
250 mV/1.5 k
Ω
Tuner section
FM frequency range
87.50–108.00 MHz
(0.05 MHz step)
FM antenna terminal
75
Ω
unbalance
AM frequency range
522–1629 kHz (9 kHz step)
520–1630 kHz (10 kHz step)
Timer section
Clock
Quartz lock type
Function
Play timer: 1 time or everyday
Rec timer: 1 time or everyday
Sleep timer: 120 min, 30 min intervals
GENERAL
Dimensions (W
H
D)
196
76.8
250 mm
Weight
1.0 k
g
AMPLIFIER
Amplifier section
(Low frequency side)
Power output
DIN 1 kHz, THD 1%, 6
Ω
both
channel driven
2
12 W
RMS 1 kHz, THD 10%, 6
Ω
both
channel driven
2
15 W
Total harmonic distortion
Half power, 1 kHz, 6
Ω
0.09%
S/N
75 dB
Load impedance
6
Ω
Amplifier section
(High frequency side)
Power output
DIN 10 kHz, THD 1%, 6
Ω
both
channel driven
2
5 W
RMS 10 kHz, THD 10%, 6
Ω
both
channel driven
2
8 W
S/N
75 dB
Load impedance
6
Ω
Headphones
Jack type
3.5 mm STEREO
Load impedance
16–32
Ω
General
Power supply
For United Kingdom, Australia and N.Z.
AC 230–240 V, 50 Hz
For others
AC 230 V, 50 Hz
Power consumption
73 W
STANDBY condition
Normal
9 W
Eco
0.8 W
Dimensions (W
H
D)
196
105.8
259.9 mm
Weight
3.3 k
g
SC-HD510
AMPLIFIER
Amplifier section
Power output
DIN 1 kHz, THD 1%, 6
Ω
both
channel driven
2
17 W
RMS 1 kHz, THD 10%, 6
Ω
both
channel driven
2
20 W
Total harmonic distortion
Half power, 1 kHz, 6
Ω
0.09 %
Frequency response
50 Hz–20 kHz (+1 dB, –3 dB)
S/N
75 dB
Load impedance
6
Ω
Headphones
Jack type
3.5 mm STEREO
Load impedance
16–32
Ω
General
Power supply
For United Kingdom
AC 230–240 V, 50 Hz
For others
AC 230 V, 50 Hz
Power consumption
67 W
STANDBY condition
Normal
9 W
Eco
0.8 W
Dimensions (W
H
D)
196
105.8
259.9 mm
Weight
2.8 k
g
CD PLAYER
Digital output terminal
Optical
1
Audio section
DA converter
1 bit 2 DAC MASH
Format
Sampling frequency
44.1 kHz
Pickup
Wavelength
780 nm
General
Dimensions (W
H
D)
196
76.8
243.1 mm
Weight
1.2 k
g
CASSETTE DECK
Audio section
Track system
4 track 2 channel STEREO
Frequency response (Dolby NR off)
(Rec/Play)
TYPE
1
(NORMAL) 30 Hz–16 kHz (DIN)
TYPE
2
(HIGH)
30 Hz–16 kHz (DIN)
TYPE
4
(METAL)
30 Hz–16 kHz (DIN)
S/N (Signal level=max recording level,
TYPE
2
)
NR off
56 dB (A weighted)
Dolby B NR
64 dB (A weighted)
Motor
Capstan drive
DC servo motor
Reel table drive
DC motor
Fast forward and rewind time (C-60)
Approx. 52 seconds
Wow and flutter
0.1% (WRMS)
General
Dimensions (W
H
D)
196
105.8
236.1 mm
Weight
1.5 k
g
SC-HD310
SPEAKER SYSTEM
Type
2 way, 2 speaker, bass-reflex system
Speaker(s)
Woofer:
12 cm cone type
Tweeter:
6 cm semi-dome type
Impedance
6
Ω
Input power
High
30 W (Music), 15 W (DIN)
LOW
60 W (Music), 30 W (DIN)
Output sound pressure level
85 dB/W (1.0 m)
Cross over frequency
5 kHz
Frequency range
43 Hz–50 kHz (–16 dB)
50 Hz–45 kHz (–10 dB)
General
Dimensions (W
H
D)
For Australia and N.Z.
155
334
240 mm
For others
155
334
252 mm
Weight
For Australia and N.Z.
3.1 k
g
For others
3.5 k
g
SPEAKER SYSTEM
Type
2 way, 2 speaker, bass-reflex system
Speaker(s)
Woofer:
12 cm cone type
Tweeter:
6 cm cone type
Impedance
6
Ω
Input power
60 W (Music), 30 W (DIN)
Output sound pressure level
85 dB/W (1.0 m)
Cross over frequency
6 kHz
Frequency range
45 Hz–25 kHz (–16 dB)
55 Hz–22 kHz (–10 dB)
General
Dimensions (W
H
D)
160
319
217 mm
Weight
3.0 k
g
Notes:
1. Specifications are subject to change
without notice.
Weight and dimensions are approximate.
2. Total harmonic distortion is measured by
the digital spectrum analyzer.
SC-HD310
SC-HD510
