TD-W8970N Wireless N ADSL2+ Modem Router User Guide
The Router's ports, where the cables are connected, and RESET button are located on the back
panel.
Figure 1-2
¾ LINE: Connect to the Modem Port of Splitter or to the telephone line.
¾ 1, 2, 3, 4 (LAN): The ports (1, 2, 3, 4) connect the Router to the local PC(s).
¾ Reset: There are two ways to reset the Router's factory defaults.
1) Use the Restore Default function on Management -> settings -> Restore Default page
in the router's Web-based Utility.
2) Use the Factory Default RESET button: With the Router powered on, use a pin to press
and hold the RESET button for at least 5 seconds. And then release the button and wait
the Router to reboot to its factory default settings.
¾ POWER: The Power plug is where you will connect the power adapter.
¾ ON/OFF: The switch for the power.
¾ Wireless Antennas: To receive and transmit the wireless data.
5
