PARTS INFORMATION
Page 2
TBC-4001
CYLINDER, PISTON, CRANKSHAFT • FIGURE 1
ITEM PART NUMBER
DESCRIPTION
QTY
COMMENTS
1
157-01570-900
CAP,SPARK PLUG,ASS'Y
1
2
018-11660-21
PLUG,SPARK
1
3
001-00045-90
SET,CYLINDER
1
Includes cylinder gasket
4
994-16050-221
SCREW,5X22/WS
2
6
017-00025-200
GASKET,CYLINDER
1
7
041-00000-21
RING,PISTON
1
8
030-00045-90
SET,PISTON
1
Includes ring and circlips
9
039-06100-200
CIRCLIP,PISTON PIN
2
10
037-06097-20
PIN,PISTON
1
12
046-00025-80
CRANKSHAFT
1
13
061-00025-800
ROD,CONNECTING
1
21
077-00025-21
CRANKCASE
1
23
999-66152-511
SEAL,OIL,#VE15X25X7
1
24
999-61600-200
BEARING,BALL,#6002
1
30
994-16040-201
SCREW,4x20 WS
2
31
155-21522-91
ROTOR,MAGNETO
1
Includes pawl and pawl spring
32
790-00025-200
SPRING,PAWL
1
33
788-00025-200
PAWL,STARTER
1
37
992-01120-011
WASHER,12
1
38
991-11120-011
NUT,12
1
50
178-00024-80
CORD
1
52
167-21533-80
COIL,IGNITION ASSY
1
