PARTS INFORMATION
[email protected] Page 9
TBC-4001
THROTTLE LEVER, HANDLE, DRIVE SHAFT, SAFETY GUARD • FIGURE 6
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
1 343-37718-00 PIPE,DRIVE SHAFT SET 1
2 300-37710-90 CASE,GEAR,ASS'Y 1
3 341-37715-20 PIPE,DRIVE SHAFT 1
4 350-37651-210 LINER,FLEXIBLE 1
5 344-37651-21 SHAFT,FLEXIBLE 1
6 304-37651-21 SHAFT,CUTTER 1
7 999-61608-004 BEARING,BALL,608DD 2
8 348-37651-20 COLLAR 1
9 990-11050-081 SCREW,5X8 1
10 300-37710-20 CASE,GEAR 1
11 994-25050-301 BOLT,PS,5X30 1
12 315-37710-200 NUT,SPECIAL 1
14 310-37710-20 HOLDER,CUTTER 1
16 885-00025-800 WIRE,THROTTLE 1
18 992-01080-011 WASHER,8 1
19 991-01080-011 NUT,8 1
20 441-37701-810 COVER,SAFETY 1
21 442-37710-200 BRACKET,SAFETY GUARD 2
22 992-10060-012 WASHER,S,6 2
23 990-23060-161 BOLT,6X16 PLUS 2
26 500-37704-20 HANDLE 1
27 991-01060-011 NUT,6 2
28 506-37704-200 BRACKET,HANDLE A 1
29 992-01060-011 WASHER,6 2
31 990-23060-401 BOLT,P,6X40 2
50 504-37400-200 GRIP,SHAFT 1
51 178-37300-801 CORD,STOP 230mm 2
52 164-10014-010 TUBE,PROTECTION 1
55 870-37400-900 LEVER,THROTTLE ASS'Y 1
56 162-37101-200 SWITCH,STOP 1
57 993-42030-081 SCREW, TAPPING, 3X8 3
58 259-37101-200 BASE,STOP SWITCH 1
59 262-37101-200 SPRING,STOP SWITCH 1
60 177-37101-200 TERMINAL,EARTH B 1
61 176-37101-200 TERMINAL,EARTH A 1
62 991-86050-000 NUT,LOCK,5 1
63 993-55060-001 RING,STOP,6 1
64 832-37101-200 SPRING,RETURN 1
65 880-37101-200 LEVER,THROTTLE 1
66 994-31050-251 SCREW,S.,5X25 1
67 853-37101-200 SHAFT,LOCK BUTTON 1
68 958-37101-200 SPRING,LOCK,BUTTON 1
69 956-37101-200 BUTTON,LOCK 1
73 320-37651-200 SPACER 1
