P
PRODUCTS
VC-04
Color Video Camera
Overall Dimensions
With pan/tilt unit:
10.5” H x 6.2” D x 3.0”
W (26.7 cm x 15.8 cm
x 7.6 cm)
Without pan/tilt unit:
5.0” H x 6.2” D x 3.0”
W (12.7 cm x 15.8 cm
x 7.6 cm)
Electrical/Environmental Specifications
Image:
1/4” IT CCD Active
Picture Elements
NTSC:
768 (H) x 494 (V)
PAL:
752 (H) x 582 (V)
Resolution:
NTSC:
470 (H) x 350 (V)
PAL:
460 (H) x 400 (V)
Signal to Noise Ratio:
min 49 dB
Video Output:
Optically encoded
NTSC or PAL
Color Balance:
Automatic Synchroniza-
tion
Operating temperature: 0° to +40° C
Storage Temperature:
-10° to +50° C
Motor Box Specifications
Houses the motors which power the pan/tilt mech-
anism.
Power:
110-220 VAC /
12 VDC
Dimensions:
7.0” H (including
mount) x 7” D x 4.7” W
(18 cm x 12 cm x 7.6
cm)
Construction: Painted
steel
Ordering Information
Product: Video
Camera
Model Number:
VC-04
Warranty:
1 year
To place an order or to learn more about the
TDK products that best meet your needs, con-
tact your TDK sales representative:
TDK RF Solutions Inc.
1101 Cypress Creek Rd.
Cedar Park, Texas 78613 USA
Phone: 1-512-258-9478
Fax: 1-512-258-0740
E-mail:
World Wide Web:
www.tdkrfsolutions.com
Rev. 2011-08-02
Optical Capabilities
Focal Length:
3.5 – 91 mm
Zoom:
26x Optical zoom
12x Digital zoom
Angular Field of View:
55° wide; 2.3° telepho-
to
Minimum Object Distance: 35 mm (wide);
800 mm (telephoto)
Angle of Pan/Tilt:
Pan: +/- 150° degrees
Tilt: +/- 30°
digress
Fiber Optic Cable:
62.5 u glass fiber
Iris Control:
Manual and
Automatic
Minimum Illumination:
0.7 lux
