VCMS-Series Video Camera Stands
Product Overview
The TDK VCMS-Series Video Camera Monopod
Stands are designed specifically for mounting a
shielded video camera in EMC test environments.
The monopod stands are constructed of durable,
non-conductive, commercial grade fiberglass and
plastic that will not interfere with RF test measure-
ments.
Each VCMS rests on a solid Delrin base that pro-
vides stability and balance for heavier equipment
but is lightweight enough to allow for ease of
movement within the test facility. The VCMS is
available in three models:
VCMS-150R The VCMS-150R telescoping mono-
pod stand easily adjusts from 100 cm to 150 cm
in height, and supports equipment up to 10 kg. It is
designed for use in anechoic chambers, shielded
rooms, and OATS.
VCMS-100RSB The VCMS-100RSB telescoping
monopod stand adjusts from 50 cm to 100 cm in
height, supports equipment up to 10 kg, and fea-
tures a support bracket to stabilize the stand
against an object. It is designed for use on car
seats to monitor the dashboard and instrument pan-
el during automotive testing.
VCMS-30 The VCMS-30 monopod stand is fixed
at 30 cm high and supports equipment up to 1.5
kg. It is designed for use in small test environments
such as a TEM cell.
Features

Three models available to fit your test require-
ments
The TDK VCMS Video Camera Monopod
Stands are built for use in EMC test environ-
ments. Camera stands are available in several
models to meet your specific requirements.
Application

Portable mounting for video cameras
