Satellite U205-S5057 Detailed Product Specification 1
Model Name Description Part Number UPC
U205-S5057 Genuine Windows Vista™ Home Premium, Intel® Core™2 Duo Processor T5500,
1024MB DDR2 SDRAM, 160GB (5400RPM), 12.1” WXGA TrueBrite™, DVD SuperMulti
Double Layer, 802.11 a/b/g, Fingerprint Reader PLUA0U-0M1042 032017778573
Operating System 2, C1
• Genuine Windows Vista™ Home Premium
o 32-bit version
Processor and Chipset 3
Intel® Centrino® Duo Mobile Technology featuring:
• Intel® Core™ 2 Duo Processor T5500 4
o 1.66GHz, 2MB L2, 667MHz FSB with 64-bit C1
• Mobile Intel® 945GM Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® PRO/Wireless 3945ABG (802.11a/b/g)
Memory
5
• Configured with 1024MB PC4200 DDR2 SDRAM (both memory
slots may be occupied)
• 512MB (Min)/4096MB (Max), with 512MB, 1024MB or 2048MB
PC4200 DDR2 memory modules.
Hard Disk Drive
6
• 160GB (5400 RPM) Serial-ATA (SATA) hard disk drive; 9.5mm
height
Fixed Optical Disk Drive
7
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (16x), DVD-ROM (8x), DVD-R (Single
Layer, (8x)), DVD-R (Double Layer, (2x)), DVD-RW (4x),
DVD+R (Single Layer, (8x)), DVD+R (Double Layer,
(2.4x)), DVD+RW (4x), DVD-RAM (3x)
Display
8
• 12.1” diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x800 native resolution (WXGA)
Graphics
9
• Intel® Graphics Media Accelerator 950 with 8MB-196MB
dynamically allocated shared graphics memory
Sound
• Built-in stereo speakers
• Windows Sound System
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• Keyboard
o 84 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Internet button to launch default browser
o CD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
Communications
• Toshiba V.92 software modem 10
• Intel® PRO/100 Network Connection - 10/100 Base-TX Ethernet
• Integrated Wireless-LAN:
11
o Intel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™,
Multi Media Card, xD Picture Card [shared slots]
o Secure Digital slot supports SDIO
Ports
• Video
o RGB (monitor) output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
o USB v2.0 – 3 ports
o RJ-45 LAN port
o RJ-11 modem port
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 11.8” (299.0mm) x 8.86” (225.0
mm) x 1.34” (34.0mm)[F]/1.37” (34.8mm)[R] without feet
• Weight: Starting at 4.1 lbs (1.86 kg) depending upon configuration 12
• Chassis Description
o Case material: Magnesium alloy + Polycarbonate ABS
o LCD Cover Color: Mist Gray
• Physical Security
o Slot for cable lock;
o Items protected by a screw: Memory, Main HDD
o Fingerprint reader
• Software Security
o Passwords: User power-on password, supervisor
password
o Hotkey locks: Screen Blank
Power Supply
• 60W (15V x 4A) Auto sensing external AC Adapter, 100-240V / 50-
60Hz frequency (Universal) input.
• Dimensions (WxDxH): 4.51” (114.5mm) x 1.14” (29.0mm) x 1.95”
(49.5mm)
• Weight: starting at 0.58 lbs (262 g)
Battery
13
• 6-cell (4700mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
• Dimensions (WxDxH): 8.15” (207.0mm) x 0.81” (20.6mm) x 1.78”
(45.1mm)
