6
Using the Extension Hose
The Extension Hose (see Figure 4) of your Hot
& Handy
™ Steam Cleaner is designed to ex-
tend the reach of the unit. One end (D) can be
inserted into the steam cleaner using steps 1
and 2 above.
Caution: End (D) of your Extension Hose may
not have Dual Alignment Marks. Be sure to
rotate 90º after inserting this end into the unit.
This will align the seam of the extender hose
with the top of the unit. Failure to do so may
allow steam to flow from the connection.
At this point either the Steam Jet Nozzle or
Large Steam Nozzle can be inserted into the
other end (E) of the Extension Hose using steps
1 and 2 above.
Assembly Instructions
Attaching the Steam Jet Nozzle or
Large Steam Nozzle
To use your Hot & Handy
™ Steam Cleaner you
need to attach the Steam Jet Nozzle or Large
Steam Nozzle to the main unit. The following
procedure works for both. (Refer to Figure 3).
1. Rotate the attachment so that the tabs (B)
align with the slots on the main unit. This
will bring the Single Alignment Mark (A)
to the top.
2. Insert the nozzle as far as it will go and
then rotate, in either direction, by 90º. This
will bring the Dual Alignment Marks (C) to
the top. The attachment is now secure.
Figure 3
Figure 4
