Toshiba SD-M2012C - Manual (Page 14)

12
Power Consumption
DC Voltage and Current Requirements 5V / 1.5A, 12V ; 1.5A
+5V +12V
Sleep
Standby 400mA
500mA 100mA
300mA
Physical
Height 1.65" (42mm)
Width 5.83" (148.2mm)
Depth 7.24" (184mm)
Weight 1.63lbs (740g)
Connectors
DC input AMP 1-480424-0
IDE Interface Connector 40 Pin ATAPI Standard
Analog Audio Line Output Connector 4 Pin ATAPI Standard (70066 Series, C Version)
Digital Audio Line Output Connector 4 Pin ATAPI Standard (70066 Series, C Version)
Regulatory
The SD-M2012C DVD-ROM drive has been certified by the following regulatory agencies:
• UL 1950
• CSA C22.2 No. 950
• TUV (EN60950I)
• CE standard
• CB
• DHHS 21 CFR Sub-Chapter J
• BSMI
