STB SPECIFICATIONS
SPECIFICATIONS(IRD)
Item Specification
Power 90 - 250VAC, 50 / 60Hz
Input Frequency 950 - 2150 MHz
1 RS - 232C, 115kbps DATA Service
SCART (SCART model only)
CINCH A/V Out
2 SCARTS: 1 VCR, 1 TV
1Video / 2 Audio (left and right)
CINCH A/V In (Non-SCART model only) 1Video / 2 Audio (left and right)
Convertible 13.5/18V (500mA max) LNB Power
Modulation / FEC Type
QPSK / Multiple convolution coding
(DVB Compliant)
DiSEqC Bus
Tone Switching
DiSEqC Ver. 1.0 / 1.2 compatible
22 KHz
RF Modulator (Non-SCART model only) UHF Ch. 21-69 with PAL I/G/B
Specification MPEG - 2/DVB Compliant SI
Video Compression MP@ML in MPEG-2
Aspect Ratio
On-Screen Display
EPG
4:3 or 16:9
256 colors with full resolution
Supported
CHANNEL PROCESSING
Item Specification
Input Frequency Range 950 - 2150 MHz
Number of Channels 3500 TV Channels and1500 Radio Channels
Tuning System PLL Digital Synthesis Channels
Tuning Step Size 125 KHz Max
QPSK (DVB Specification) Modulation
Rates: 1/2, 2/3, 3/4, 5/6, 7/8
(DVB Specification)
Inner FEC
Outer FEC Reed Solomon coding RS (204, 188, t=8)
Input Symbol Rate 2 to 45 Ms/s
IF Bandwidth
Connector Type
27MHz
F Type ( IEC 169 - 24 female)
