Texas Instruments TPA2008D2 User Manual
Page 24
TPA2008D2 EVM Parts List
3-4
Reference
3.3
TPA2008D2 EVM Parts List
Table 3–1. TPA2008D2 EVM Parts List
Reference
Description
Size
EVM
Qty.
Manufacturer/
Part Number
Vendor/
Part Number
C1, C2, C3,
C4
Capacitor, 0.1
µ
F,
±
5%,
X7R, 16 V
603
4
Panasonic
ECJ–1VB1C104K
Digi-Key
PCC1762CT–ND
C5, C7, C8,
C9, C10
Capacitor, 1
µ
F,
80%/–20%, Y5V, 10 V
603
5
Panasonic
ECJ–1VF1A105Z
Digi-Key
PCC1787CT–ND
C6
Capacitor, 220 pF,
±
5%,
X7R, 16 V
603
1
Yageo America
06032R221K9B20D
Digi-Key
311–1077–1–ND
C11
Capacitor, 10
µ
F,
80%/–20%, Y5V, 16 V
1210
1
Murata
GRM32NF51C106ZA01L
R1, R2
Resistor, 120 k
Ω
, 1/16
W, 5%
603
2
Panasonic
ERJ–3GEYJ124V
Digi-Key
P120K6CT–ND
R3
Potentiometer, 50 k
Ω
,
Cermet ST SL, thru hole
1
Bourns
3362P–1–503
Digi-Key
3362P–1–503–ND
S1
Switch, momentary
pushbutton, 12 V, 50 mA
SMD
1
Panasonic
EVQ–PPBA25
Digi-Key
P8086SCT–ND
Headers, 0.1 in centers,
1/2 in long
0.5 X
0.25 X
0.1”
7
Samtec
TSW–19–8–G–S
U1
IC, 2-W, stereo class-D
audio power amplifer
24-pin
TSSOP
1
TI
TPA2008D2PWP
PCB
PCB, 2 layer, fits U2 on
PnP
2.25 X
1.25”
1
TI
SLOP392
