11-32
11. PROGRAMMING PROCEDURES
11.19 FREE FORMAT
Address
Address
Commodity
(0,0) (383,0)
Label Length
384 dot
57 mm
Y
X
*1
*2
*1
*1 Address are printed together with the previous
label’s data. To print addresses, use normal
labels.
POS (Format #10-16): 10.0 mm
NET (Format #21-26): 10.0 mm
Bar code (Format #31-36): 8.5 mm
*2 Free format area
↑ ↑ ↑ ↑
A B C D
ABC
D
A B C D
ABC
D
6. When pressing the TEST key, the printer issues a test label.
7. Rotated data will be printed so that the lower left corner is positioned at the designated
coordinate.
(1) 0
°
(2) 90
°
(3) 180
°
(4) 270
°
The points indicates by the arrows are the designated coordinates.
8. Print coordinate
When setting the print item positions (X and Y), an error will occur
in the following cases.
1 Entered “X” point + Print size “X” > 384 dots.
2 Entered “Y” point + Print size “Y” > 1301 dots.
Magnified print items become double in size.
No.
23
24
25
26
27
28
29
30
31
138
105
140
105
106
105
138
105
320
32
13
20
13
20
13
32
13
118
32
13
20
20
13
32
13
146
120
147
112
120
146
120
(F) Prince
(F) Price (title)
(F) Unit price
(F) Unit price (title)
(F) Weight
(F) Weight (title)
(F) Price
(F) Price (title)
(F) LOGO
Print Item
Print area size
Rotation
Note
Normal
X Y X Y
13 120
