Toastmaster CONVEYOR TC2000 - Manual (Page 6)

6
E
Wiring Diagram - Model TC2000, 380-400V, 3-Phase
Electrical Schematic -
Model TC2000, 380-400V, 3-Phase
A Middleby Company
Toastmaster • 1400 Toastmaster Drive • Elgin, IL 60120 • USA • (847)741-3300 • FAX (847)741-4406
Middleby Corp 24-Hour Service Hotline 1-800-238-8444
www.middleby.com
Electrical
Specifications:
380-400V, 50Hz,
3 Ph, 5.0kW
Current draw:
N 11.0A
L1 0.6A
L2 11.0A
L3 11.0A
Cord and Plug
Information: N/A
TERMINAL BLOCK
POT 1
100K Ω
UPR
TEMP
CTRL
UPPER
HEATING ELEMENT
POT 2
100K Ω
LWR
TEMP
CTRL
LOWER
HEATING ELEMENT
CONTACTOR
TSTAT
N.O.
TSTAT
N.C.
FAN
POWER
ON/OFF
(I/O)
SWITCH
RFI
FILTER
MOTOR
FUSE
0.25 A
CONVEYOR
SPEED
CONTROLLER
POT
1M Ω
L1 L2 L3 N
LINE FILTER
TSTAT
N.O.
TSTAT
N.C.
FAN
MOTOR
FUSE 0.25 A
RFI FILTER
CONVEYOR
SPEED
CONTROLLER
UPPER HEATING ELEMENT
LOWER HEATING ELEMENT
POT
100K Ω
UPPER TEMP
CONTROL
LOWER TEMP
CONTROL
C
POWER ON/OFF (I/O) SWITCH
2 POLE
POT
1M Ω
POT
100K Ω
(N)
C1
(L1)
C2
(L2) (L3) E
C3 C4
LINE FILTER
