MM101332V1, Rev. K
3. Press
.
The backlight menu item is activated. Line one shows the active menu item and its current
parameter setting. Line two shows the currently selected system or group name (see Figure 10-2).
Figure 10-2: Backlight Menu Display
4. The menu item's parameter setting shown in the display can now be changed by using

or

.
5. Once the desired setting is reached press

to store the value and return the menu option selection
level.
For menu items that display radio information pressing

or

will scroll through a list of
informational displays. An example of information displays is shown in Figure 10-3.
The TX POWER menu item, when selected, toggles LOW/HIGH power. It does not use

or

to scroll nor is an additional press of the

button required.
35
