Tricity Bendix TBG700 - Manual (Page 14)

14
Burner Dia. Tap By-pass
1/100 mm
Auxiliary 28
Semi-rapid 32
Rapid 40
Triple crown 56
Aeration adjustment none
BURNER RAPID SEMI-RAPID A U X I L I A R Y TRIPLECROWN
POSITION M A X MIN M A X MIN M A X MIN M A X MIN
NOMINAL THERMAL
POWER
kW 3.0 0.65 2.0 0.45 1.0 0.33 4.0 1.2
NOMINAL FLOW
RATE
m 3 /h 0.286 0.062 0.190 0.043 0.095 0.031 0.381 0.114
NOZZLE REFERENCE
119 Adjust. 96 Adjust. 70 Adjust. 146 Adjust.
1/100 mm
NOMINAL THERMAL
POWER
kW 2.8 0.65 2.0 0.45 1.0 0.33 4.0 1.2
NOMINAL FLOW
RATE
g/h 202 47 144 32 72 24 288 86
NOZZLE REFERENCE
86 40 71 32 50 28 98 56
1/100 mm
NATURAL GAS
20 mbar
VALUE =
37.78 MJ/m 3
Ws - 50.7 MJ/ m 3
TYPE OF GAS
LPG GAS
28-30/37 mbar
VALUE =
49.92 MJ/Kg
