Trace Oxygen Analyzer
Teledyne Analytical Instruments
Specific Model Information
The instrument for which this manual was supplied may incorporate one or
more options not supplied in the standard instrument. Commonly available
options are listed below, with check boxes. Any that are incorporated in the
instrument for which this manual was supplied are indicated by a check mark in
the box.
Instrument Serial Number: __________________________
The instrument with the above serial number has the following
Options:
❏ 3020T-C
Three gas inputs, for sample, zero and span gases, with
three solenoid-actuated gas-flow control valves built in.
Valves are automatically synchronized to the analyzer's
electronic control sequences.
❏ 3020T–F
Built-in flame arresters for Groups C and D service.
❏ 3020T–G
Built-in flame arresters for Groups C and D service, plus
gas-control valves as in –C option, above.
❏ 3020T–H
Built-in flame arresters for Group B (hydrogen) service.
❏ 3020T–I
Built-in flame arresters for Group B (hydrogen) service,
plus gas-control valves as in –C option, above.
❏ 19" Rack Mount
The 19" Relay Rack Mount units are available with
either one or two series 3000 analyzer Control Units
installed in a standard 19" panel and ready to mount in a
standard rack. See Appendix for details.
❏ Cell Class*
____________________
(L-2C standard).
Enter Class Designation
*
See Part II, Chapter 2 and/or any addendum that may be
attached to this manual for cell specifications.
