TQ-445 TQ-425 TQ-115
Dimensions 588 x 409 x 363mm
23.1” x 16.1” x 14.3” 836 x 511 x 632mm
32.9” x 20.1” x 24.9” 559 x 450 x 578mm
22” x 17.7” x 22.8”
Net weight 30 kgs
66 lbs 54 kgs
118.8 lbs 30.1 kgs
66.2 lbs
Power handling LF: 600watts rms
1200 watts program
MF/HF: 300 watts rms
600 watts program 800 watts rms
1600 watts program 400 watts rms
800 watts program
Sensitivity
(1w @ 1m) 103dB 100dB 96dB
Frequency
response
(±4dB) 75Hz – 20kHz 55Hz – 200Hz 70Hz – 200Hz
Nominal
dispersion
(@ -6dB points) 60°h x 40°v n/a n/a
Maximum SPL 129dB 130dB 136dB
Connectors (2) Neutrik Speakon
NL4MP (2) Neutrik Speakon
NL4MP (2) Neutrik Speakon
NL4MP
Due to continuing product improvement the above specifications are subject to change.
