MODELS 630C, 634A & 634K
REF
NO.
PART NO.
DESCRIPTION
1
736-0159
Flat Washer, 5/16 (B)
2
714-0139
Key, 3/16" x 2"
1108841
Key, 3/16" x 1.5” (C)
3
1916531
Pulley, Engine Drive
619-04016
Pulley, Engine Drive (C)
4
1916532
Transmission Pulley (B)
656-04023
Transmission Pulley (A)
5
1916535
Pulley, Reverse Idler (B)
6
1916652
Guard, Belts/Pulleys
7
1916657
Forward Drive Belt
8
1916658
Reverse Drive Belt (B)
9
1916660
Belt Cover
10
1916724
Reverse Return Spring (B)
11
1916725
Reverse Belt Guide (B)
12
1916726
Forward Belt Guide
13
1916794
Engine Bracket, Left
14
1916795
Engine Bracket, Right
15
1917326
Bracket, Belt Cover
16
1917746
Shoulder Washer
17
1918731
Reverse Idler Arm (B)
18
1918744
Forward Idler Lever
19
710-0117
Hex Hd. Screw, 5/16-24 x 1
20
710-0237
Hex Hd. Screw, 5/16-24 x 5/8
21
710-0376
Hex Hd. Screw, 5/16-18 x 1
22
710-04049
Hex Hd. Screw, 5/16-18 x 5/8
(A) For Model 630C
(B) For Model 634A and 634K
(C) For Model 634K Only
(D) For Model 634A Only
23
710-0520
Hex Hd. Screw, 3/8-16 x 1-1/2
24
710-0599
Screw, Self-Tapping, 1/4-20 x 1/2
25
710-3103
Hex Hd. Screw, 5/16-18 x 2 (B)
26
712-3000
Lock Nut, 3/8-16
27
712-3009
Lock Nut, 5/16-18 (B)
28
736-0119
Lock Washer, 5/16
29
736-3050
Flat Washer, 3/8
30
736-3090
Flat Washer
31
710-0151
Hex Hd. Screw, 3/8-24 x 2.00
710-0459A
Hex Hd. Screw, 3/8-24 x 1.50 (C)
32
GW-1138-2
Shim (D)
736-0315
Flat Washer,.75 x 1.5 x.125 (A)
33
GW-50027
Support Washer
34
GW-55034
Forward Return Spring
35
GW-55049
Bracket, Cable Mounting
36
GW-9090
Forward Idler Pulley
37
GW-9301
Key, 3/16" x 1"
38
736-3078
Flat Washer
39
GW-9944
Belleville Washer
40
710-0672
Hex Hd. Screw, 5/16-24 x 1.25 (A)
41
710-0805
Hex Hd. Screw, 5/16-18 x 1-1/2 (A)
42
712-3010
Hex Nut, 5/16-18 (A)
43
736-0242
Bell Washer,.340 x.872 x.060 (A)
44
736-0452
Bell Washer,.396 x 1.140 x.095
45
750-0258
Spacer,.315 x.750 x 375 Lg (A)
REF
NO.
PART NO.
DESCRIPTION
