18
Door Reversal
If required the direction of the door can be changed
as follows:
In figure the TB 110 FF appliance can be seen.
Remove carefully (e.g. with a knife) the covering
nails of screws fixing the bottom cover grid, then
the cover grid can be removed by unscrewing the
plate-screws (2 pieces).
Dismount the bottom door holder of the freezer by
removing the screws (2 pieces) and the fill plates (2
pieces).
Take off the door of the freezer by pulling it slightly
downwards.
Dismount the double door holder by removing the
screws (2 pieces) and the fill plates (2 pieces).
Take off the door of the refrigerator by pulling it
slightly downwards.
Unscrew the top door holding pin of the
refrigerator, then screw it back on the other side.
Remove the covering nails of the double door
holder on the left side and put them to the other
side.
Fit the door of the refrigerator to the top door
holding pin.
Fix the double door holder onto the left side using
the screws (2 pieces) and fill plates (2 pieces). Be
careful that the door edge of the refrigerator is
parallel with the edge of the mantle.
Fit the door of the freezer to the double door
holding pin.
Fix the bottom door holder onto the left side using
the screws (2 pieces) and fill plates (2 pieces). Be
careful that the door edge of the freezer is parallel
with the edge of the mantle.
Pull out the cover element of the cover grid in the
direction of arrow (1) and place it on the contrary
side (2).
Put the cover grid back and fix it with the plate-
screws (2 pieces), then put the covering nails back.
Put the appliance to its place, set it level and apply
voltage to it.
In case you do not want to perform the procedures
above, call the nearest brand-mark service.
Technicians will accomplish the refitting expertly for
charge.
