Tricity Bendix TB 110 FF - Manual (Page 16)

16
Ins Ins tr tr uctions f uctions f or the Ins or the Ins t t aller aller
Technical data
Model
Gross capacity (l)
Net capacity (l)
Width (mm)
Height (mm)
Depth (mm)
Energy consumption (kWh/24h)
(kWh/year)
Energy class, according to EU standards
Freezing capacity (kg/24h)
Rising time (h)
Rated power (W)
Weight (kg)
Number of compressors
TB 110 FF
Freezer: 105
Refrigerator: 195
Freezer: 80
Refrigerator: 192
600
1790
600
1,42
518
C
18
20
150
65
1
Installing the appliance
Transportation, unpacking
It is recommended to deliver the appliance in
original packaging, in vertical position
considering the protective warning on packaging.
After each transportation the appliance must not be
switched on for approx. 2 hours.
Unpack the appliance and check if there is any
damage. Report possible damage immediately to the
retailer.
Location
The appliance should be positioned in a well
ventilated, dry room.
Energy use is affected by the ambient temperature.
The appliance should therefore:
not be installed next to radiators, cookers or
other sources of heat
only be installed at a location where the ambient
temperature corresponds to the climate
classification, for which the appliance is
designed.
The climate classification can be found on the serial
plate.
The following table shows which ambient
temperature is correct for each climate
classification:
Climate Classification Ambient Temperature
SN +10 to +32 °C
N +16 to +32 °C
ST +18 to +38 °C
If installation next to a source of heat is
unavoidable, the following minimum clearances
must be maintained at the sides of the appliance:
for electric cookers 3 cm
for oil and coal fired ranges 30 cm
