9
Switch
BRIDGE 1
BRIDGE 2
CH 1 mode
ON
ON
ON
Setting
CH1
CH1
CH2
CH3
CH4
BRIDGE 1 BRIDGE 2
Speaker output terminals
8 Ω
8 Ω
- + - +
[1 input - 2 outputs]
CH1
- +
CH2
- +
Speaker output terminals
Switch
BRIDGE 1
BRIDGE 2
CH 1 mode
OFF
ON
OFF
Setting
4 – 8 Ω
4 – 8 Ω
8 Ω
CH1
CH2
CH3
CH1
CH2
CH3
CH4
BRIDGE 2 - +
[3 inputs - 3 outputs (1)]
CH3
- +
CH4
- +
Speaker output terminals
Switch
BRIDGE 1
BRIDGE 2
CH 1 mode
ON
OFF
OFF
Setting
8 Ω
4 – 8 Ω
4 – 8 Ω
CH3
CH4
CH1
CH3
CH4
CH1
CH2
BRIDGE 1 - +
[3 inputs - 3 outputs (2)]
BRIDGE 1 BRIDGE 2
Speaker output terminals
Switch
BRIDGE 1
BRIDGE 2
CH 1 mode
ON
ON
OFF
Setting
8 Ω
8 Ω
CH1
CH3
CH1
CH2
CH3
CH4
- + - +
[2 inputs - 2 outputs]
CH4
- +
CH3
- +
CH2
- +
CH1
- +
Speaker output terminals
Switch
BRIDGE 1
BRIDGE 2
CH 1 mode
OFF
OFF
ON
Setting
4 – 8 Ω
4 – 8 Ω
4 – 8 Ω
4 – 8 Ω
CH1
CH1
CH2
CH3
CH4
[1 input - 4 outputs]
