INSTALLATION
• Connect one end of the line cord to the telephone line wall socket and the other end to the
bottom of the phone.
• Put batteries in the battery compartment to activate the display :
- Open the battery compartment at the bottom of the unit.
- Insert 4 AA batteries (1,5V).
- Close the battery compartment.
Instead of using batteries, you can also use an adapter (DC 9V / 300 mA (
))
(adapter not included).
Note: The memories remain saved, even without batteries or electricity supply (flash memory) !
2
BUTTONS/LED
1
Erase/Mute-button
2
‘Handsfree’ indicator
3
‘New Calls’ indicator
4
Memory button
5
Direct Memory
button 2
6
Direct Memory
button 1
7
Flash
8
Down button
9
Up button
10 Dial back button
11 Set button
12 Redial / Pause button
13 Phone Book button
14 Voice Mail button
VM
15 Handsfree button
16 Alphanumerical buttons
17 Ring volume switch
18 Adapter input
19 Telephone line input
20 Headset connection (optional)
21 Headset/Handsfree selection switch (optional)
