This product specification is variable and subject to change prior to product launch.

© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite U305-S7477 Rev. 1.30 2007-10-16 DM T20070803 CB1.20

Page 3 of 6

Satellite U305-S7477 Detailed Product Specification

1

Model Name

:

U305-S7477

Part Number: PSU30U-054012

UPC: 032017981379

Operating System

C1

2

• Genuine Windows Vista

®

Home Premium (32-bit version)

Processor and Chipset

3

• Intel® Core™ 2 Duo Processor T7250

o

2.0GHz, 2MB L2, 800MHz FSB

• Mobile Intel® GM965 Express Chipset

• Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)

4

Memory

5

• Configured with 2048MB PC2-5300 DDR2 SDRAM (both memory slots

may be occupied). Maximum capacity 4096MB

Hard Disk Drive

6

• 200GB (4200 RPM) Serial ATA hard disk drive

Fixed Optical Disk Drive

7

• DVD SuperMulti (+/-R double layer) drive supporting 11 formats

o

Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),

CD-RW (16x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-
RAM (5x)

Display

8

• 13.3” diagonal widescreen TruBrite®TFT LCD display at 1280 x 800

native resolution(WXGA)

Graphics

9

• Intel® Graphics Media Accelerator X3100 with 64MB-251MB

dynamically allocated shared graphics memory

Sound

• Built-in stereo speakers
• Sound Volume Control Dial

• Built-in microphone

Input Devices

• 86 key US keyboard

• TouchPad™ pointing device
• TouchPad™ Enable/Disable

• Control Buttons:

o

Internet button to launch default browser

o

CD/DVD control buttons (Play/Pause, Stop, Prev Track, Next

Track)

Communications

• Webcam and microphone built into LCD bezel

• Modem

10

• 10/100 Ethernet
• Integrated Wi-Fi® compliant wireless:

11

o

Intel® Wireless WiFi Link 4965AG (802.11a/g)

4

o

Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)

Expandability

• 2 main memory slots. Both slots may be occupied.
• ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)

• 5-in-1 Bridge Media Adapter

o

Secure Digital, Memory Stick™, Memory Stick PRO™, Multi

Media Card, xD Picture Card [shared slots]

Ports

• Video

o

RGB (monitor) output port

• Audio

o

Microphone input port

o

Headphone output port

• Data

o

i.LINK(tm)

IEEE-1394

o

USB v2.0 – 3 ports

o

RJ-45 LAN port

o

RJ-11 modem port

• Security

o

Fingerprint

reader

Physical Description

• Dimensions (WxDxH Front/H Rear): 12.2” x 8.94” x 1.34” /1.33” without

feet

• Weight: Starting at 4.54 lbs depending upon configuration

12

LCD Cover Color: Onyx Blue Metallic

Power

• 75W (19V 3.95A) Auto sensing

,

100-240V/50-60Hz AC Adapter.

o

Dimensions

(WxDxH):

5.0” x 2.0” x 1.2”

o

Weight: starting at 0.77 lbs

Battery

13

• 7800mAh Lithium Ion battery pack

Software

C1

14

• Toshiba Software and Utilities

o

TOSHIBA Value Added Package

o

Electronic User’s Guide

o

Bluetooth Stack for Windows by Toshiba

o

TOSHIBA

ConfigFree®

o

TOSHIBA

Disc

Creator

o

TOSHIBA DVD Player

o

TOSHIBA Extended Tiles for Windows Mobility Center

o

TOSHIBA Speech System

• Third-party Software

o

TOSHIBA Game Console

o

Microsoft Works Version 8.5

o

Sun® Java™ 2 Runtime Environment

o

Adobe® Acrobat® Reader 8.0

o

InterVideo®WinDVD®

8

o

Google™

Desktop

o

Google™

Toolbar

o

Google

Picasa™

o

Yahoo! Music™ Jukebox

o

Ulead® DVD MovieFactory® 5 for TOSHIBA

• Trial Software

o

Microsoft Office Trial Home and Student 2007 Edition (60-day trial)

o

McAfee® Internet Security Suite (30-day trial)

• Special Offers

o

Microsoft Office Live

o

Shutterfly digital photo service

o

Napster® music subscription service

o

eMusic MP3 music subscription service

o

VONGO

SM

internet video download service

o

ebay®

o

CNN

Pipeline

o

Skype™

internet

communications

Environmental Specifications

Operating

Non-operating

Temperature

15

5° to 35° C
(41° to 95° F)

-20° to 60° C
(-4° to 149° F)

Thermal Gradient

18° C per hour (max)

18° C per hour (max)

Relative Humidity
(non-condensing)

20% to 80%

10% to 90%

Altitude
(relative to sea level)

0 to 3,000 meters

0 to 10,000 meters

Shock 10G 60G
Vibration 0.5G

1.0G

• This product is RoHS

16

compatible

1 YEAR STANDARD LIMITED WARRANTY

17

Service Upgrades and Extensions
