O W N E R ’ S M A N U A L
•
E 8 5 S E 8 5
89
E85
1
233 1056
User interface (incl.. 2 - 4)
1
-
M5x8 DIN 7500
Screw
2
2
173 1069
Lower cover
1
-
KB 30x8 WN 1411
PT-screw
6
3 433
1022
Guard
plate
1
4
403 1096
Silicone keyboard
5
173 1070
Bottle track
1
-
KB 30x8 WN 1411
PT-screw
4
6
103 1047
Meter bracket
1
-
M5x12 DIN 7985
Screw
1
7
203 1041
Handle bar for hgp, (incl.8,94)
1
-
203 5006
Handle bar, (incl. 8, 94)
1
8
213 1008
Handle grip, pair (incl. 9)
1
9 533
7039
Plug
2
10
433 1021
Handle pulse unit only hgp
(incl.11-12 and screw)
1
-
403 0043
Pulse transmitter belt (no hgp)
1
13
403 1090
Cable, set (incl.13a,13d, 13e)
1
13b 403
1054
Sensor
1
- M3,5x13DIN7504-N
Screw
2
13c 403
1026
Magnet
1
13g 403
1099
DC-wire
1
13h 403
9004
RJ45
1
14 173
1024
Bezel
1
17 103
1050
Frame
1
-
M6 DIN 985
Nut, nylon
1
-
M6x20 DIN 933
Screw
1
18
533 507 82
Stand plug, front and rear
4
-
M6x16 DIN 603
Screw, front
2
-
M6 DIN 934
Nut, front
2
-
KB 50x14WN-1442
PT-Screw, rear
2
19
423 1115
Label, set
1
20
173 1071
Side cover, LH
1
173 1072
Side cover, RH
1
-
M4 DIN 9021
Washer
3
- KB40x40
WN-1442 PT-Screw
3
22 653
1017
Nut
2
-
12x18x05 DIN 988
Washer
1
24
303 1016
Flywheel (incl. 41, 42)
1
-
17x24x15 DIN 988
Washer
1
30
533 1039
Sleeve (incl.17x24x1 DIN988)
1
31
403 0048EU
Transformer, EUR
1
-
403 0048USA
Transformer, USA
1
32
403 1093
Control card
1
-
M5 DIN 934
Nut
2
-
M4x25 DIN 7500C
Screw
1
33
403 1050
El. magnet
1
-
M6 DIN 125
Washer
4
-
M6x50 DIN 931
Screw
4
36
673 500 88
Snap locking
2
37 533
1048
Wheel
2
38
173 1075
Rear support
1
* -
M8 DIN 9021
Washer
2
* -
M8x20 DIN 912
Screw
2
-
173 1076
Rear compl. (18,36-39,96,
fastening
parts)
1
39
103 1022
Wheel base
1
-
2,9x10 DIN 7981
Screw
1
* -
M8 DIN 125
Washer
2
* -
M8x20 DIN 912
Screw
2
40
643 104 89
Spring
1
41
523 504 84
Bearing
1
42 523
1010
Bearing
1
43
523 409 85
Bearing
4
44 343
1010
Axle
1
45
443 1009
Transmission belt
1
47
513 1003
Belt tightener frame
1
-
12x18x05 DIN 988
Washer
1
-
M10 DIN 125
Washer
1
-
10 DIN 471
Retaining
1
51
693 1003
Slide piece
2
-
M5 DIN 125
Washer
1
-
M5x8 DIN 7500-C
Screw
1
52
653 1022
Locking knob
1
-
17x24x1 DIN988
Washer
1
53 263
1007
Wheel
1
-
17 DIN 471
Retaining
1
54
353 1004 1
Crank, left, T-info 10/00
1
-
353 1005 1
Crank, right
1
55
653 0073
Screw-plug, T-info 13/00
1
56
363 1002
Pedal band, pair
1
57
363 1001
Pedal, pair (incl. part 56)
1
58
693 1002
Slide piece
1
-
M4x8 DIN 7500-C
Screw
4
60
653 1003
Clip nut
1
61
153 1014
Seat tube
1
-
M8 DIN 985
Nut, nylon
1
-
M8x60 DIN 916
Screw, Tinfo 28/99
1
62 423
1053
Label
1
64 203
1039
Handlebar
1
-
M8x25 DIN 7984
Screw
2
65
153 1013
Seat base (incl.M8x60 DIN 916)
1
-
M8 DIN 9021
Washer
2
-
M8x20 DIN 912
Screw
2
67
153 1004
Lower cover
1
-
M4 DIN 9021
Washer
3
- KB40x12WN-1411 PT-Screw,
rear
2
- KB40x20WN-1411 PT-Screw,
front
1
68 503
1020
Retainer
3
71 153
1009
Seat
1
-
153 1016
compl.(67,82,65,fastening parts)
1
72
173 1073
Front cover
1
-
M5x20 DIN 7985
Screw
1
82
653 1008
Adjusting wheel
1
86
683 1001
Rubber washer
2
87
72 8012 602
Sleeve
2
88
403 1102EU
Mains cable, EUR
1
-
403 1102US
Mains cable, USA
1
-
403 1102US
Mains cable, AUS
1
-
403 1102US
Mains cable, GB
1
91
533 1019
Adjuster knob
1
-
M8x80 DIN 603
Screw 8.8
1
93 523
1018
Sleeve
1
94
513 1008
Tightener
1
95 523
1019
Sleeve
1
96
653 236 83
Washer
4
*107 533 1040
Plug, pair
1
122 103 1024
Front support
1
* -
M8 DIN 125
Washer
4
* -
M8x25 DIN 7984
Screw
4
-
103 1033
Front support compl.
(96, 122, fastening parts)
1
*
553 1008
Assembly kit (incl. * )
1
*
553 100 88
Multi purp. wrench
1
*
556 0001
Allen key 6 mm
1
*
556 031 00
Allen key 5 mm
1
*
553 0013
Screw - Shaped
1
-
583 1032
Owner´s manual
1
-
583 0006
Warranty booklet
1
