Tunturi E85S User Manual
Page 87
O W N E R ’ S M A N U A L
•
E 8 5 S E 8 5
87
E85S
1
2331056
User interface (incl. 2-4)
1
-
M5x10 DIN 7500 Screw
2
2 1731069 Lower
cover
1
- KB30x8
WN
1411
PT-screw
6
3 433
1022 Guard
plate
1
4
403 1096
Silicone keyboard
1
5
173 1070
Bottle track
1
-
KB 30x8 WN 1411 PT-screw
4
7
203 1040
Handle bar for hgp, (incl.8)
1
-
203 1043
Handle bar (incl. 8)
1
8
213 1009
Handle grip, pair (incl. 9)
1
9 533
7039 Plug
2
10
433 1021
Handle pulse unit only hgp
(incl. 11, 12 and screw)
1
-
403 0043
Pulse transmitter belt (no hgp)
1
13
403 1091
Cable, set (incl. 13a,13e)
1
13b
403 1054
Sensor
1
-
M3,5x13DIN 7504-N Screw
2
13c 403
1026
Magnet
1
13g 403
1099
DC-wire
1
17 103
1018 Frame
1
-
M8 DIN 985
Nut, nylon
1
-
M8 DIN 137A Washer
1
-
M8x60 DIN 933 Screw
1
18
533 507 82
Stand plug, front and rear
4
-
M6x16 DIN 603 Screw, front
2
-
M6 DIN 934
Nut, front
2
-
KB50x14WN-1442 PT-Screw, rear
2
19
423 1116
Label, set (incl. 19a -19b)
1
20
173 1071
Side cover, L
1
-
173 1072
Side cover, R
1
-
M4 DIN 9021 Washer
3
- KB40x40WN-1442
PT-Screw
3
22 653
1017 Nut
2
- 12x18x05
DIN988
Washer
1
24 303
1016 Flywheel
1
-
17x24x15 DIN 988 Washer
1
30
533 1039
Sleeve (incl. 17x24x05 DIN 988) 1
31
403 0048EU
Transformer, EUR
1
-
403 0048 USA Transformer, USA
1
32
403 1093
Control card
1
-
M5 DIN 934
Nut
2
-
M4x25 DIN 7500-C Screw
1
33
403 1050
El. magnet
1
-
M6 DIN 125 Washer
4
-
M6x50 DIN 931 Screw
4
36
673 500 88
Snap locking
2
37 533
1048 Wheel
2
38
103 1075
Rear support
1
-
103 1076
R.compl.(18,36,39,96,fastening pcs) 1
-
M8 DIN 9021 Washer
2
-
M8x20 DIN 912 Screw
2
39
103 1022
Wheel base
1
-
2,9x10 DIN 7981 Screw
1
-
M8 DIN 125
Washer
2
-
M8x20 DIN 912 Screw
2
40
643 104 89
Spring
1
41
523 504 84
Bearing
1
42 523
1010 Bearing
1
43
523 409 85
Bearing
4
44 343
1010 Axle
1
45
443 1009
Transmission belt
1
47
513 1006
Belt tightener frame
1
- 12x18x05
DIN988
Washer
1
-
M10 DIN 125 Washer
1
-
10 DIN 471
Retaining
1
51
693 1003
Slide piece
2
-
M5 DIN 125 Washer Zn
2
-
M5x8 DIN 7500-C Screw
1
52
653 1022
Locking knob
1
-
17x24x05 DIN 988 Washer
1
53
263 1007
Wheel
1
-
17 DIN 471
Retaining
1
54
353 1004 1
Crank, L
1
-
353 1005 1
Crank, R
1
55 653
0073 Screw-plug
1
57
362 8013
Pedal, pair
1
58
693 1002
Slide piece
1
-
M4x8 DIN 7500-C Screw
4
60
653 1003
Clip nut
1
61
153 1023
Upper frame
1
62
423 1053
Label
1
65
153 1018
Seat base
1
68 503
1020 Retainer
3
71 152
8053 Seat
1
72
173 1074
Front cover
1
-
M5x20 DIN 7985 Screw
1
88
403 1102EU
Mains cable, EUR
1
-
403 1102USA Mains cable, USA
1
-
403 1102AUS Mains cable, AUS
1
-
403 1102GB
Mains cable, GB
1
90 503
1022 Plate
1
94
513 204 82
Clamp
1
96
653 236 83
Washer
4
107
533 1040
Plug, pair
1
112
203 1042
Handlebar support
1
116
512 1003
Seat clamp
1
117
173 1037
Upper frame bezel
1
118
533 122 83
Sleeve
1
119
513 1007
Locking lever
1
120
533 238 87
Sleeve
1
122
103 1024
Front support
1
-
103 1033
Front compl.(18,96, fastening pcs) 1
-
M8 DIN 125
Washer
4
-
M8x25 DIN 7984 Screw
4
128 533
1052
Plug
1
129 533
1042
Plug
1
130 533
1041
Plug
1
131 522
8009
Sleeve
1
132 533
1045
Sleeve
1
*
553 1010
Assembly kit (incl. *)
1
*
553 100 88
Multi purp. wrench
1
*
556 335
Allen key 4 mm
1
*
553 0013
Screw - Shaped
1
-
583 1032
Owner’s manual
1
-
583 0006
Warranty booklet
1
