13
Appendix D Specifications
Inputs: Analog audio:
1 Single-ended per channel (RCA).
1 Balanced per channel (XLR).
Input Impedance: 50 K Ω Single-Ended or Balanced, for each phase.
Input sensitivity: (Single-Ended) 1.5V RMS input for 100W into 8 ohms.
(Balanced) 0.75V RMS input for 100W into 8 ohms.
Gain: (Single-Ended) 25.5dB (19x).
(Balanced) 31.5dB (38x).
Polarity: (Single-Ended) Non-Inverting.
(Balanced) Pin-2 = Positive, Pin-3 = Negative for Non-Inverting Output.
Outputs: Analog
Audio: 1 balanced output per channel.
I/O RS232: 1 DB9 and 1 RJ45 connector.
Modes/Processes: Standby: All channels are muted and output bias is reduced to 40%.
Thermal: One or more channels has overheated; amp automatically switches to Standby.
Power Output:
(8 ohms-one channel driven) 100 W (rated) 130 W (typical)
(8 ohms-five channels driven) 100 W (rated) 115 W (typical)
(4 ohms-one channel driven) 200 W (rated) 210 W (typical)
Frequency Response: (-3dB points @ full power) 0.9 Hz - 350 KHz.
THD+Noise: <2%
Signal to Noise Ratio: (unweighted) >100dB
Power Requirements: 117 VAC, 7.7 amp; 230 VAC, 4 amp; 50-60 Hz; for full power in all channels.
Power Consumption: 80W @ Standby; 100W @ idle; 900W @ full power.
Standby Trigger Input: 5-12 VDC Pulse between 1 and 500mS.
Dimensions: 17 5/8" W x 6 1/4" H x 20 1/2" D (448 x 159 x 521 mm)
Weight:
58 Lbs. Stand alone (26.3 Kg), 64 Lbs. Boxed with accessories (29 Kg)
Maximum Operating Temperature: Internal: 176 ° F (80 ° C)
Room: 131 ° F (55 ° C)
