Reference Materials
A. Heater Dimensions
27-5/8 in.
(702 mm)
26 in.
(661 mm)
16 in.
(407 mm)
4-1/4 in.
(108 mm)
22-5/8 in.
(575 mm)
22-7/8 in.
(581 mm)
18-5/8 in.
(473 mm)
9-1/4 in.
(235 mm)
1/2 in.
(13 mm)
1 in.
(26 mm)
1 in.
(26 mm)
