Ad-s82h response, beamwidth, and impedance curves – QSC Audio AD-S82H User Manual
Page 11
EN
11
Frequency (Hertz)
Frequency (Hertz)
Horizontal
Vertical
Be
am
wi
d
th (
d
eg
re
e
s)
SP
L (dB)
On Axis
20° Off Axis
40° Off Axis
Impedance
Im
ped
ance
(oh
m
s)
AD-S82H Response On-Axis, 20° Off-Axis, 40° Off-Axis, and Impedance Vs. Frequency
AD-S82H Horizontal and Vertical Beamwidth Vs. Frequency
AD-S82H Response, Beamwidth, and Impedance Curves
Specifications are subject to change without notice.
