BURNER MANUFACTURER: Beckett NX
Boiler Model
B-3
B-4
B-5
B-6
Burner Model
NEC-1102*
NEC-1101*
NEC-1101*
NEC-1103*
Firing Rate
0.55
0.90
1.00
1.20
Insertion Depth
3.50"
6.00"
6.00"
6.00"
Nozzle
0.50 X 60
0.65 X 60
0.75 X 60
0.90 X 60
Spray Pattern
hollow
solid
solid
W
Pump Pressure
180 psi
180 psi
180 psi
180 psi
Head Type
NX70LC
NX90LB
NX90LB
NX90LB
Head Position
0.75
2.75
3.75
3.75
BURNER MANUFACTURER: Beckett AFII
Boiler Model
B-4
B-5
B-6
B-7
Burner Model
NEC-301*
NEC-302*
NEC-303*
NEC-303*
Firing Rate
0.8
1
1.25
1.5
Insertion Depth
2.75"
2.75"
2.75"
2.75"
Nozzle
0.65 X 60
0.85 X 60
1.00 X 60
1.10 X 60
Spray Pattern
hollow
solid
solid
Solid
Pump Pressure
160 psi
140 psi
160 psi
185 psi
Head Type
6 slot
6 slot
9 slot
9 slot
Head Position
3
4
5
6
BURNER MANUFACTURER: Beckett AFG
Boiler Model
B-3
B-4
B-5
B-6
B-7
Burner Model
NEC 1301
NEC 1302
NEC 1303
NEC 1304
NEC 1304
Firing Rate
0.55
0.80
1.00
1.25
1.50
Insertion Depth
2.75"
2.75"
6.0"
3.5"
3.5"
Nozzle
0.50 x 60
0.75 X 60
0.75 X 60
1.10 X 60
1.35 X 60
Spray Pattern
Solid
Solid
Solid
Solid
Solid
Pump Pressure
180 psi
150 psi
175 psi
125 psi
125 psi
Head Type
L1
L1
V 1
V 1
V 1/2 Setting
A ir Shutter
8.0
10.0
7.0
10.0
10.0
A ir Band
0.0
0.0
0.0
1.0
3.0
*The highlighted burners are
not listed by ULC and may
not be installed on Biasi
equip ment in Canada.
This page is only for boilers using an oil burner. If a gas burner is being used,
please refer to page 19 for the proper setup of the burner and gas lines.
BURNER MANUFACTURER
Heat Wise
Pioneer
Boiler Model
B-3
B-4
B-5
B-6
B-7
B-8
B-9
Burner Model
P-1 FV
(1)
P-1 KA
P-1 KA
P-2 KA
P-2KA
P-2KA
P-2KA
Firing Rate
0.55
0.90
1.00
1.25
1.50
1.8
2.1
Nozzle
0.40 X 80
0.65 X 70
0.85 X 70
1.00 X 80
1.25 X 80
1.5 X 80
1.75 X 70
Spray Pattern
Solid
Solid
Semi Solid
Hollow
Hollow
Hollow
Solid
Pump Pressure
190
190
140
155
145
145
140
Head Setting
1
1
1
3.75
6
10.75
14.25
Air Setting
0
9.5
16.5
6
11
6
11
1) 120-mm Fan Needed
BURNER MANUFACTURER
Boiler Model
B-3
B-4
B-5
B-6
B-7
B-8
B-9
Burner Model
F-3
F-3
F-5
F-5
F-5
F-10
F-10
Firing Rate
0.55
0.80
1.00
1.25
1.50
1.80
2.10
Insertion Depth
3.0"
3.0"
3.0"
3.0"
3.0"
3.0"
3.0"
Nozzle
0.50 X 80
0.65 X 80
0.85 X 60
1.00 X 60
1.25 X 60
1.50 X 60
1.75 X 60
Spray Pattern
W
W
W
W
W
B
B
Pump Pressure
145 PSI
145 PSI
145 PSI
145 PSI
145 PSI
145 PSI
145 PSI
Turbulator
1
2
2
3
4
2
3
Air Gate
2-2.7
3.5-4.5
2.8-.3.4
3-5
4.5-6
2.8-3.4
3-4.1
Riello F-40 Series
8.1 Oil Burner Setup
