S P E C I F I C AT I O N S S P É C I F I C AT I O N S TECHNISCHE DATEN ESPECIFICACIONES
PL218
PL224
PL230
PL236
OUTPUT POWER
in watts
FTC:
8
ohms per channel (20 Hz–20 kHz, 0.03% THD) 310 440 575 725
4
ohms per channel (20 Hz–20 kHz, 0.05% THD) 525 725 900 1100
EIA: 1 kHz @ 1% THD
8
ohms per channel 340 475 625 800
4
ohms per channel 600 825 1050 1300
2
ohms per channel 900 1200 1500 1850
Bridged Mono:
16
ohms, 20 Hz–20 kHz, 0.1% THD 650 900 1200 1500
8
ohms, 20 Hz–20 kHz, 0.1% THD 1100 1500 1800 2400
4
ohms, 1 kHz, 1% THD 1800 2400 3000 3600
DYNAMIC HEADROOM
N/A N/A
N/A
N/A
DISTORTION (all models)
SMPTE-I
M Less than 0.01%
Typical, 10 dB below rated power, 20
Hz–20 kHz
<0.015
Typical, full rated power, 5
kHz
FREQUENCY RESPONSE (all models) 20 Hz to 20 kHz, ±0.2 dB
(at 1
0 dB below rated output power) -3 dB points: 8 Hz and 100 kHz
DAMPING FACTOR (all models)
Greater than 500
NOISE (unweighted, 20-20k Hz.)
-107 dB -108 dB -107 dB -107 dB
VOLTAGE GAIN
32 dB
34 dB
35 dB
36 dB
INPUT SENSITIVITY, V
rms
for rated power into 8
ohms 1.23 V 1.16 V 1.17 V 1.23 V
for rated power into 4
ohms 1.16 V 1.10 V 1.07 V 1.07 V
INPUT CLIPPING, Vrms (all models)
10 V
INPUT IMPEDANCE (all models) 6
k
W unbalanced
12
k
W balanced
CONTROLS (all models)
Front: AC switch, Ch. 1 and Ch. 2 gain knobs
Rear: DIP Switch for Ch.1and Ch.2: clip limiter on/off, LF fliter on/off, LF filter freq. select 30 or 50 Hz., inputs parallel or stereo, bridge mode
INDICATORS (all models)
POWER ON: Green LED
CLIP/Protect:
Red LED, 1 per channel
STANDBY:
POWER LED 1/2 brightness
Level -10 dB:
Amber LED, 1 per channel
BRIDGED:
Yellow LED
Level -20 dB:
Green LED, 1 per channel
PARALLEL:
Orange LED
SIGNAL -35dB :
Green LED, 1 per channel
CONNECTORS (all models)
Input:
XLR (pin 1, earth; pin 2, +; pin 3, -) and 1/4" (6.3 mm) TRS (tip, +; ring, -; sleeve, earth) and 3-pin detachable terminal block (pin out labeled)
Output:
“Touch-Proof” binding posts and Neutrik® Speakon connectors
36
<0.01%
