12

Dimensions- WL2102 and WL2102-w

NOTE! Composite enclo-
sures have approximately
1° of draft on the enclosure
sides; the birch plywood
enclosures do not.

Handle orientation may
vary between composite
and plywood enclosures.

20.75” (527mm)

10.75” (273mm)

20.4” (518mm)

7.7” (196mm)

27.5” (699mm)

26.8” (681mm)

10.1”

(257mm)

25.0” (635mm)
