9 Specifications
Bus interface: PCI, 32-bit bus, Universal Voltage
Signaling
IBM-compatible computers
Dimensions: approx. 5.0" x 2.5"
Serial ports Controller: 16750-compatible with 64-byte FIFOs
Interface: One female 68-pin VHDCI connector to:
Eight male D-9 connectors using adapter cable
-or-
Eight female 10-pin RJ-45 connectors using
adapter cable
Transceivers: ISL4245EIR
High-level output: +5V min
Low-level output: -5V max,
Switching speed
Power requirements: +5 volts; approx. 150 mA
Temperature: operating 0° to 70° / storage -50°
to 80°
Humidity: 10% to 90%
ESC(LP)-100 User's Manual 30
