15

PROTECTION CIRCUITS

The design goal in high-efficiency amplifiers such as the CX Series is to increase the amplifier’s ability to deliver

peak power without increasing its size, weight, and cost. However, the higher power flow through the output

components makes effective, responsive protection circuitry absolutely vital. To this end, the design of the CX

series takes a comprehensive approach to protection.

As in all QSC amplifiers, the inputs are resistively buffered for overload and RF protection. Chassis bypass

capacitors at inputs and outputs further improve RF rejection.

CX amplifiers use the proven Ouput Averaging

short circuit protection system. This circuit permits full output

current even into resistive or reactive 2-ohm loads, but reduces the current safely by about 75% if the output

is shorted.

Turn-on/turn-off muting keeps transients-both from the amplifier itself and from upstream equipment-from

reaching the speakers when the amplifier is turned on or off. The turn-on delay is approximately three seconds

to allow the power supplies and circuitry to stabilize. Turn-off muting occurs almost immediately after power

is shut off. Muting occurs whether power is turned on and off using the front panel power switch or externally

at the AC source.

Inside a CX6, CX6T, CX12, or CX12T amplifier, an NTC (negative temperature coefficient) thermistor in series

with the power switch and transformer primary limits inrush current. The thermistor initially has a high resistance,

which then diminishes rapidly as it warms, to avoid power loss. Typically, the inrush current of an CX Series

amplifier thus is equal to that of another amplifier of about 1/3 to 1/2 its power rating. The low inrush of the

smaller CX4 and CX4T does not require an NTC thermistor.

When the DC fault protection circuitry of a CX6, CX6T, CX12, or CX12T senses a DC voltage on a channel output,

it actuates a relay which shorts the output and load to ground. The amplifier’s Output Averaging protection

circuitry will limit current to further protect the output devices. If the DC problem persists, that channel will go

into thermal protection mode and should be serviced by a qualified technician.

The output stage of a CX4 or CX4T channel has AC coupling to prevent it from passing DC.

Temperature sensors on the channel heatsinks and the power transformers are part of the thermal management

circuitry. The temperature sensors govern whether the dual-speed fan should run at low or high speed. Below

55½C, the fan runs at low speed; above, it runs at high speed. At or above 85½ C, the channel mutes to go into

thermal protection.

Built-in second-order 50 Hz (CX4T) and third-order 45 Hz (CX6T and CX12T) Butterworth high-pass filtering helps

prevent saturation in speaker transformers on distributed lines by sharply reducing the amount of ultra-low

frequency energy the amplifier puts out. However, some lower-quality speaker transformers have rated low-

frequency responses that do not even extend as low as these filters; if you have any of these in your distributed

line system you should insert corresponding high-pass filtering in the audio path before the amplifier.
