Quadra-Fire • QV36DC-A • 2161-900 Rev. C • 6/09

16

HORIZONTAL VENTING

Kit No.

H Max. Run

DVP-TRAP

24” (610 mm)

Figure 10. Corner Installation

NOTE: This model is tested and approved to use
45° elbows in corner installations. However, 90°
elbows will result in better performance.

Figure 9. Horizontal Installation

90-DEGREE
ELBOWS

45-DEGREE
ELBOW

H
