The following instructions provide step-by-step instructions on viewing
resources used by the QSC(LP)-100 in Windows using the "Device Manager"
utility. Select Start|Help from within Windows for additional information on this
utility.
1. Double click the "System" icon inside the Control Panel folder. This
opens up the System Properties box.
2. Click the "Device Manager" tab located along the top of the System
Properties box. This lists all hardware devices registered inside the
Windows registry. Additional information is available on any of these
devices by click on the device name and then selecting the "Properties"
button.
3. Double click the device group "Multi-function Adapters". The
QSC(LP)-100 model name should appear in the list of Multi-function
adapters.
4. Double click the QSC(LP)-100 model name and a properties box should
open for the hardware adapter.
5. Click the "Resources" tab located along the top of the properties box to
view the resources Windows has allocated for the QSC(LP)-100 match
the hardware configuration. Because PCI is a true plug-and-play bus,
do not attempt to modify the configuration values listed. Click
"Cancel" to exit without making changes.
