13
SPEAKER IMPEDANCE
4 OHMS MIN. PER EACH
SPEAKER TERMINAL
AC INLET SEVEN CHANNEL AMPLIFIER
MODEL NO. RDA-7.1
INPUT
SELECT
FUSE
SURROUND BACK
RIGHT SURROUND
RIGHT
12V TRIGGER
IN OUT
SURROUND
LEFT
CENTER
FRONT
LEFT
SURROUND BACK
LEFT FRONT
RIGHT
INPUT
SELECT INPUT
SELECT INPUT
SELECT INPUT
SELECT INPUT
SELECT INPUT
SELECT
OUTPUT OUTPUT OUTPUT OUTPUT OUTPUT OUTPUT OUTPUT
L
R
L
R
FRONT
CENTER
SURR SURR BACK
SUB
WOOFER
( ASSIGNABLE )
( SINGLE )
Note:
When using the RCA inputs,
do not connect anything to the
balanced inputs.
Improper connection
Inserted completely
Connecting to the RDC-7.1
Since many users will purchase the RDA-7.1 together with the RDC-7.1, here is an explanation of how to connect
the RDA-7.1 to the RDC-7.1.
Balanced input/output connection
Unbalanced input/output connection RCA type cable
Connect to the RDC-7.1 12V TRIGGER OUT E terminal.
(Use the supplied stereo mini-plug cable when making
connection.)
RDA-7.1
RDC-7.1
Push the INPUT
SELECT switch
downward
Note:
When using the balanced
inputs, do not connect
anything to the RCA inputs.
RDC-7.1
SURR BACK R SURR R FRONT R CENTER FRONT L SURR BACK L SURR L SUBWOOFER
PRE OUT A (SINGLE)
)
(ASSIGNABLE) (ASSIGNABLE)
SPEAKER IMPEDANCE
4 OHMS MIN. PER EACH
SPEAKER TERMINAL
SEVEN CHANNEL AMPLIFIER MODEL NO. RDA-7.1
INPUT
SELECT
FUSE
SURROUND BACK
RIGHT SURROUND
RIGHT
12V TRIGGER
IN OUT
SURROUND
LEFT
CENTER
FRONT
LEFT
SURROUND BACK
LEFT FRONT
RIGHT
INPUT
SELECT INPUT
SELECT INPUT
SELECT INPUT
SELECT INPUT
SELECT INPUT
SELECT
AC INLET
OUTPUT OUTPUT OUTPUT OUTPUT OUTPUT OUTPUT OUTPUT
RDA-7.1
At the RDC-7.1
XLR type
At the RDA-7.1
Connect to the RDC-7.1 12V TRIGGER OUT E terminal.
(Use the supplied stereo mini-plug cable when making
connection.)
Balanced cable
Push the INPUT SELECT
switch upward
