3.2 Gain Setting
The high grade instrumentation provides software programmable gains or
switch selectable gain of 0.5 1, 5, 10, 50, 100, 500, 1000.
Software Setting : JP18 should be place on “R”
Switch Setting : JP18 should be place on “L”
Software Setting
(Remote control)
Switch Setting
(Local Control)
Gain
DO 6
DO 5
DO 4
SW1-3
SW1-2
SW1-1
0 0 0 ON
ON
ON
0.5
0 0 1 ON
ON
OFF
1
0 1 0 ON
OFF
ON 5
0 1 1 ON
OFF
OFF
10
1 0 0
OFF
ON
ON
50
1 0 1
OFF
ON
OFF
100
1 1 0
OFF
OFF
ON
500
1 1 1
OFF
OFF
OFF
1000
